Clinical efficacy of occlusive splints manufactured by computer modeling and volumetric printing in patients with bruxism: research results and a clinical case
- Authors: Apresyan S.V.1, Stepanov A.G.1, Gadzhiev M.A.2, Borodina I.D.2, Heigetyan A.V.2
-
Affiliations:
- RUDN University
- RUDN University of Russia
- Issue: Vol 26, No 3 (2022)
- Pages: 199-211
- Section: Clinical Investigation
- Submitted: 05.07.2022
- Accepted: 05.07.2022
- Published: 28.09.2022
- URL: https://rjdentistry.com/1728-2802/article/view/109190
- DOI: https://doi.org/10.17816/1728-2802-2022-26-3-199-211
- ID: 109190
Cite item
Abstract
BACKGROUND: Among dental diseases, various types of musculoskeletal dysfunctions occupy a special place. The myogenic theory of temporomandibular joint dysfunction is interesting, where the fundamental role is assigned to the parafunctional state of the masticatory muscles. Analysis of the results of electromyographic studies has shown that patients with TMJ disorders complicated by muscle hypertension have significant functional disorders of the masticatory muscles. Also, the causes of TMJ dysfunction include bruxism, which can occur against the background of parafunctions of the masticatory muscles. To date, there are a large number of methods for the treatment of TMJ dysfunction: splint therapy, occlusive and immobilizing splints. CAD/CAM computer technologies have also become widespread, which are used for the manufacture of these structures. But there are no uniform treatment standards, therefore, studies and comparisons of different techniques are relevant.
AIM: the effectiveness of treatment of patients with bruxism by developing a clinical protocol for the use of an occlusive splint made by volumetric printing.
MATERIAL AND METHODS: To evaluate the effectiveness of occlusive splints manufactured by computer milling and 3D printing in patients with bruxism. All study participants at the stage of formation of clinical groups underwent a comprehensive dental examination, which included a clinical and instrumental examination, surface electromyography of the masticatory muscles, computer monitoring of occlusion, cone-beam computed tomography of the TMJ. To exclude the somatoform component from the pathogenesis of bruxism, an electroencephalogram (EEG) was performed in all patients at the stage of formation of clinical groups. At the first stage of treatment, all patients underwent selective grinding of centric and eccentric interferences under the control of a T-scan computer occlusion monitoring device, after which the therapeutic position of the mandible was determined, stabilizing nocturnal occlusal splints made by volumetric printing were manufactured and fixed. Monitoring of treatment results included clinical and instrumental examination and surface electromyography of the masticatory muscles, carried out 3.6 and 12 months after the start of treatment. Upon completion of treatment, an assessment of the integrity of occlusal splints was carried out.
RESULTS: According to the results of the performed myography, at the time of the start of treatment, the PU coefficient was 74%, after 3 months, it significantly decreased by 6%, after 6 months, its decrease was recorded by 11%, and after 12 months — by 16%. The assessment of the integrity of the occlusal splint was carried out at the end of treatment after 12 months, by combining virtual tire models in a computer program before and after the start of treatment obtained by laboratory scanning. When analyzing the comparison of virtual tire models, their almost complete identity was revealed, with the exception of one area on the occlusal surface, which is 0.044 mm, which is not critical in the general treatment concept.
CONCLUSION: Taking into account the positive result of clinical testing of the proposed technology, it is advisable to conduct a randomized study to evaluate the effectiveness of the use of occlusive splints made by computer modeling and volumetric printing from domestic material in the treatment of patients with musculoskeletal dysfunction complicated by bruxism.
Keywords
Full Text
About the authors
Samvel V. Apresyan
RUDN University
Author for correspondence.
Email: dr.apresyan@gmail.com
ORCID iD: 0000-0002-3281-707X
MD, Dr. Sci. (Med.), Professor
Russian Federation, MoscowAlexander G. Stepanov
RUDN University
Email: stepanovmd@list.ru
ORCID iD: 0000-0002-6543-0998
MD, Dr. Sci. (Med.), Professor
Russian Federation, MoscowMagammed A. Gadzhiev
RUDN University of Russia
Email: dr.gadjievma@mail.ru
ORCID iD: 0000-0003-1878-503X
MD, Postgraduate Student
Russian Federation, MoscowIrina D. Borodina
RUDN University of Russia
Email: 7599839@gmail.com
ORCID iD: 0000-0002-4278-2026
MD, Postgraduate Student
Russian Federation, MoscowArtur V. Heigetyan
RUDN University of Russia
Email: artur5953@yandex.ru
ORCID iD: 0000-0002-8222-4854
MD, Cand. Sci. (Med.), Associate Professor
Russian Federation, MoscowReferences
- Bezrukov VM, Semkin VA, Grigoryants LA, Rabukhina NA. Diseases of the temporomandibular joint: a textbook. Moscow: GEOTAR-MED; 2002. 48 p. (In Russ).
- Khaibullina RR, Gerasimova LP, Baikov DA, et al. Computed tomography in diseases of the temporomandibular joint. Kazan Medical Journal. 2008;89(1):56–57. (In Russ).
- Rabukhina NA, Golubeva GI, Perfiltsev SA. Spiral computed tomography in diseases of the maxillofacial region. Moscow: MEDpress-inform; 2006. 128 p. (In Russ).
- Herb K, Cho S, Stiles MA. Temporomandibular joint pain and dysfunction. Curr Pain Headache Rep. 2006;10(6):408–414. doi: 10.1007/s11916-006-0070-7
- Katzberg RW, Tallents RH. Normal and abnormal temporomandibular joint disc and posterior attachment as depicted by magnetic resonance imaging in symptomatic and asymptomatic subjects. J Oral Maxillofac Surg. 2005;63(8):1155–1161. doi: 10.1016/j.joms.2005.04.012
- Uryaseva EV. Dynamics of the degree of activity of periodontal enzyme systems against the background of traumatic occlusion. Kuban Scientific Medical Bulletin. 2009;(2):129–132. (In Russ).
- Trezubov VN, Bulycheva EA, Posokhina OV. Study of neuromuscular disorders in patients with TMJ disorders complicated by masticatory muscle parafunctions. Institut Stomatologii. 2005;(4):85–89. (In Russ).
- Manfredini D, Landi N, Tognini F, et al. Occlusal features are not a reliable predictor of bruxism. Minerva Stomatol. 2004;53(5):231–239.
- Kozlov DL, Vyazmin AYa. Etiology and pathogenesis of temporomandibular joint dysfunction syndrome. Siberian Medical Journal. 2007;(4):5–7. (In Russ).
- Okeson JP; American Academy of Orofacial Pain. Orofacial pain: guidelines for assessment, diagnosis and management. Chicago: Quintessence; 1996. 285 p.
- Mayboroda YuN, Khorev OYu. Neuromuscular and joint dysfunction of the temporomandibular joint. Kuban Scientific Medical Bulletin. 2017;(3):142–148. (In Russ). doi: 10.25207/1608-6228-2017-24-3-142-148
- Puzin MN, Vyazmin AYa. Pain dysfunction of the temporomandibular joint. Moscow: Meditsina; 2002. 160 p. (In Russ).
- Puzin MN, Kiparisova ES, Bodneva SL. Comprehensive assessment of nonspecific risk factors in generalized periodontitis. Russian Journal of Dentistry. 2003;(2):29–35. (In Russ).
- Al-Ani MZ, Davies SJ, Gray RJ, et al. Stabilisation splint therapy for temporomandibular pain dysfunction syndrome. Cochrane Database Syst Rev. 2004;(1):CD002778. doi: 10.1002/14651858.CD002778.pub2
- Watkins SJ, Hemmings KW. Periodontal splinting in general dental practice. Dent Update. 2000;27(6):278–285. doi: 10.12968/denu.2000.27.6.278
- Naumovich SS, Razorenkov AN. CAD/CAM systems in dentistry: current state and development prospects. Sovremennaya Stomatologiya. 2016;(4):2–9. (In Russ).
- Apresyan SV, Stepanov AG, Antonik MM, et al. Complex digital planning of dental treatment. Moscow: Mozartika; 2020. 396 p. (In Russ).
- Apresyan SV, Stepanov AG, Vardanyan BA. Digital protocol for comprehensive planning of dental treatment. Clinical case analysis. Stomatologiya. 2021;100(3):65–71. (In Russ). doi: 10.17116/stomat202110003165
- Apresyan SV, Stepanov AG, Retinskaya MV, Suonio VK. Development of complex of digital planning of dental treatment and assessment of its clinical effectiveness. Russian Journal of Dentistry. 2020;24(3):135–140. (In Russ). doi: 10.17816/1728-2802-2020-24-3-135-140
- Apresyan SV, Suonio VK, Stepanov AG, Kovalskaya TV. Evaluation of functional potential of CAD-programs in integrated digital planning of dental treatment. Russian Journal of Dentistry. 2020;24(3):131–134. (In Russ). doi: 10.17816/1728-2802-2020-24-3-131-134
