Research of a flat in phase two-dimensional-periodic overrange antenna array of flared notch hornes

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

Using numerical modeling, a study was carried out of the matching and radiation characteristics of a flat in-phase two-dimensional - periodic over-band antenna array of flared-notch horns depending on the period and length of the array elements, input and output impedance, type of feed lines and screen shape. A 64-way power divider with outputs in the form of symmetrical two- strip lines has been developed and studied, and an 8 × 8 array of elements with a power divider as a power feed system has been studied. It is shown that the array with the U-shaped screen provides an operating frequency bandwidth of more than 20:1.

Full Text

Restricted Access

About the authors

M. D. Duplenkova

Kotelnikov Institute of Radio Engineering and Electronics of RAS

Email: vak@cplire.ru
Russian Federation, Mokhovaya Str., 11, build. 7, Moscow, 125007

V. A. Kaloshin

Kotelnikov Institute of Radio Engineering and Electronics of RAS

Author for correspondence.
Email: vak@cplire.ru
Russian Federation, Mokhovaya Str., 11, build. 7, Moscow, 125007

The Thanh Nguyen

Moscow Institute of Physics and Technology (National Research University)

Email: vak@cplire.ru
Russian Federation, Institutsky per., 9, Dolgoprudny, Moscow region, 141700

References

  1. Kindt R.W., Pickles W.R. // IEEE Trans. 2010. V. АР-58. № 11. Р. 3568.
  2. Дупленкова М.Д., Калиничев В.И., Калошин В.А. // Журн. радиоэлектрон. 2015. № 11. http://jre.cplire.ru/jre/nov15/13/text.pdf
  3. Kалошин В.А., Нгуен К.З. // Журн. радиоэлектрон. 2017. № 5. http://jre.cplire.ru/jre/may17/14/text.pdf
  4. Банков С.Е., Калошин В.А., Нгуен К.З. // РЭ. 2018. Т. 63. № 7. С. 702.
  5. Kindt R.W., Logan J.T. // IEEE Antennas and Propagation. Magaz. 2018. V. 60. № 3. Р. 34.
  6. Logan J.T., Kindt R.W., Vouvakis M.N. // IEEE Trans. 2018. V. АР-66. № 4. Р. 1827.
  7. Банков С.Е, Калошин В.А, Ле Н.Т. // РЭ. 2018. V. 63. № 12. С. 1263.
  8. Kалошин В.А., Ле. Н.Т. // Докл.VI Всерос. Микроволновой конф. Москва. 28–30 нояб. 2018. М.: ИРЭ им. В. А. Котельникова РАН, 2018. С. 194.
  9. Kaloshin V.A., Le N.T. // Proc. Int. Conf. “2019 Radiation and Scattering of Electromagnetic Waves (RSEMW)”, Divnomorskoe. 24–28 Jun. N.Y.: IEEE, 2019. Р. 32. http: doi.org/10.1109/RSEMW.2019.8792733
  10. Kалошин В А., Ле Н.Т. // РЭ. 2019. V. 64. № 11. С. 1126.
  11. Kindt R.W., Logan J.T. // IEEE Trans. 2020. V. АР-68. № . 4. Р. 2666.
  12. Kалошин В.А., Ле Н.Т. // РЭ. 2020. V. 65. № 10. С. 979.
  13. Kалошин В.А., Ле Н.Т. // Журн. радиоэлектрон. 2020. № 3. http://jre.cplire.ru/jre/mar20/8/text.pdf
  14. Kалошин В.А., Ле Н.Т., Фролова Е.В. // Журн. радиоэлектрон. 2020. № 4. http://jre.cplire.ru/jre/apr20/2/text.pdf
  15. Дупленкова М.Д., Калошин В А. // РЭ. 2021. Т. 66. № 12. С. 1165.
  16. Дупленкова М.Д., Калошин В.А. // РЭ. 2022. Т. 67. № 7. C. 645.

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Fig. 1. Floquet channel for a phased array of slot horns: isometric view (a) and cross-section (b).

Download (241KB)
Indexing metadata
3. Fig. 2. Frequency dependence of the reflection coefficient of infinite gratings for the model shown in Fig. 1: with a period of 15 mm × 15 mm and an input resistance of 50 Ohm (curve 1) and 100 Ohm (curve 3); with a period of 10 mm × 15 mm and an input resistance of 50 Ohm (curve 2) and 100 Ohm (curve 4).

Download (241KB)
Indexing metadata
4. Fig. 3. Infinite lattice model, lumped port excitation.

Download (200KB)
Indexing metadata
5. Fig. 4. Frequency dependence of the reflection coefficient of infinite gratings for the model shown in Fig. 3: with a period of 15 mm × 15 mm and an input resistance of 50 Ohm (curve 1) and 100 Ohm (curve 3); with a period of 10 mm × 15 mm and an input resistance of 50 Ohm (curve 2) and 100 Ohm (curve 4).

Download (184KB)
Indexing metadata
6. Fig. 5. Frequency dependence of the reflection coefficient of an infinite grating for L = 100 (1), 150 (2), 200 (3) mm.

Download (123KB)
Indexing metadata
7. Fig. 6. 256-element in-phase antenna array: (a) – with a flat screen, (b) – with a U-shaped screen.

Download (269KB)
Indexing metadata
8. Fig. 7. Frequency dependence of the reflection coefficient for gratings with a period of 15×15 mm and a flat screen (a), a U-shaped screen (b). Curves 1–4 correspond to the number of grating elements: 64, 144, 256, ∞. The input resistance in all cases is 50 Ohm.

Download (177KB)
Indexing metadata
9. Fig. 8. Frequency dependence of the reflection coefficient for gratings with 64 elements and a flat screen (a), and a U-shaped screen (b). Curves 1 and 3 correspond to a grating period of 15 mm × 15 mm and an input resistance of 50 and 100 Ohms; curves 2 and 4 correspond to a grating period of 15 mm × 15 mm and an input resistance of 50 and 100 Ohms.

Download (177KB)
Indexing metadata
10. Fig. 9. Frequency dependence of the reflection coefficient for gratings with 64 elements with a period of 15 mm × 15 mm and a flat screen (a), a U-shaped screen (b) with different element lengths L: 100 (1), 150 (2) and 200 mm (3).

Download (175KB)
Indexing metadata
11. Fig. 10. Directional patterns of a 64-element in-phase array with a flat screen in the E-plane (a) and H-plane (b) at frequencies of 0.5 (1), 5 (2), 9 (3) and 11 (4) GHz.

Download (337KB)
Indexing metadata
12. Fig. 11. Directional patterns of a 64-element in-phase array with a U-shaped screen in the E-plane (a) and H-plane (b) at frequencies of 0.5 (1), 5 (2), 9 (3) and 11 (4) GHz.

Download (188KB)
Indexing metadata
13. Fig. 12. Directional patterns of a 256-element in-phase array with a flat screen in the E-plane (a) and H-plane (b) at frequencies of 0.5 (1), 5 (2), 9 (3) and 11 (4) GHz.

Download (210KB)
Indexing metadata
14. Fig. 13. Directional patterns of a 256-element in-phase array with a U-shaped screen in the E-plane (a) and H-plane (b) at frequencies of 0.5 (1), 5 (2), 9 (3) and 11 (4) GHz.

Download (201KB)
Indexing metadata
15. Fig. 14. Frequency dependences of the gain of a 64-element (curves 1, 2) and 256-element in-phase array (curves 3, 4) with different screens. Curves 1, 3 correspond to a U-shaped screen, and curves 2, 4 – to a flat screen.

Download (48KB)
Indexing metadata
16. Fig. 15. Frequency dependences of the forward-to-backward radiation ratio of a 64-element (curves 1, 2) and 256-element in-phase array (curves 3, 4) with different screens. Curves 1, 3 correspond to a U-shaped screen, and curves 2, 4 to a flat screen.

Download (50KB)
Indexing metadata
17. Fig. 16. Antenna array with a divider: (a) – with a flat screen, (b) – with a U-shaped screen.

Download (252KB)
Indexing metadata
18. Fig. 17. Coaxial power divider; top – longitudinal section, bottom – diagram.

Download (93KB)
Indexing metadata
19. Fig. 18. Strip power divider; top – longitudinal section, bottom – diagram.

Download (147KB)
Indexing metadata
20. Fig. 19. Frequency dependence of the divider reflection coefficient calculated using FEM (1) and MKRVO (2).

Download (63KB)
Indexing metadata
21. Fig. 20. Frequency dependence of the power divider gain: outputs 1–8 (a), outputs 9–16 (b), outputs 17–24 (c), outputs 25–32 (d). Curves 1: outputs 1, 9, 17, 25; curves 2: outputs 2, 10, 18, 26; curves 3: outputs 3, 11, 19, 27; curves 4: outputs 4, 12, 20, 28; curves 5: outputs 5, 13, 21, 29; curves 6: outputs 6, 14, 22, 30; curves 7: outputs 7, 15, 23, 31; curves 8: outputs 8, 16, 24, 32.

Download (337KB)
Indexing metadata
22. Fig. 21. Frequency dependence of the phases of the divider gain coefficients: outputs 1–8 (a), outputs 9–16 (b), outputs 17–24 (c), outputs 25–32 (d). Curves 1: outputs 1, 9, 17, 25; curves 2: outputs 2, 10, 18, 26; curves 3: outputs 3, 11, 19, 27; curves 4: outputs 4, 12, 20, 28; curves 5: outputs 5, 13, 21, 29; curves 6: outputs 6, 14, 22, 30; curves 7: outputs 7, 15, 23, 31; curves 8: outputs 8, 16, 24, 32.

Download (240KB)
Indexing metadata
23. Fig. 22. Power supply system output diagram.

Download (125KB)
Indexing metadata
24. Fig. 23. Frequency dependence of the reflection coefficient of a grating with a divider and: a U-shaped screen (1), a flat screen (2), without a screen (3).

Download (71KB)
Indexing metadata
25. Fig. 24. Smooth transition from strip line to slot horn.

Download (81KB)
Indexing metadata
26. Fig. 25. Frequency dependence of the reflection coefficient of a grating with a U-shaped screen and smooth transitions: without a divider (1), with a divider (2).

Download (75KB)
Indexing metadata
27. Fig. 26. Directivity patterns of an antenna array with a U-shaped screen in the E-plane (a) and H-plane (b) at frequencies of 0.5 (1), 5 (2), 9 (3) and 11 (4) GHz.

Download (209KB)
Indexing metadata
28. Fig. 27. Directivity patterns of an antenna array with a flat screen in the E-plane (a) and H-plane (b) at frequencies of 0.5 (1), 5 (2), 9 (3) and 11 (4) GHz.

Download (206KB)
Indexing metadata
29. Fig. 28. Frequency dependences of the gain (curves 1, 2) and the forward-to-backward radiation ratio (curves 3, 4) of a 64-element in-phase antenna array. Curves 1, 3 correspond to a U-shaped screen, curves 2, 4 – to a flat screen.

Download (88KB)
Indexing metadata
