High-performance concrete for industrial construction and mechanical engineering

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription or Fee Access

Abstract

The multicomponent composition of the raw material mixture and the heterogeneity of the structure of highly functional concretes at various scale levels make it possible to effectively control the formation of indicators of its damping properties due to prescription and technological factors. Experimental compositions included Portland cement, quartz sand, granite screening, silica, metacaolin, quartz flour, microcalcite, shrinkage compensators, hyperplasticizer and reinforcing microfiber. The hydrodynamic properties were investigated by methods of free and forced oscillations.Experimental compositions included Portland cement, quartz sand, granite screening, silica, metacaolin, quartz flour, microcalcite, shrinkage compensators, hyperplasticizer and reinforcing microfiber. The hydrodynamic properties were investigated by methods of free and forced oscillations.Experimental compositions included Portland cement, quartz sand, granite screening, silica, metacaolin, quartz flour, microcalcite, shrinkage compensators, hyperplasticizer and reinforcing microfiber. The hydrodynamic properties were investigated by methods of free and forced oscillations.A laboratory complex of vibrodynamic tests has been developed that provides automated processing of the amplitudes of bending damping vibrations of the first mode of concrete samples to calculate the dynamic modulus of elasticity and the logarithmic decrement of attenuation. The high accuracy of the results obtained made it possible to identify the nature of the influence of various prescription factors (consumption of cement, pozzolan additives, microfiber, shrinkage compensators) on the dynamic modulus of elasticity and damping of concrete. An increase in the value of concrete damping (by 1.22 times) was established with an increase in cement consumption from 300 to 734 kg/m3. The introduction of shrinkage compensators, differing in the mechanism of action, made it possible to obtain non-shrinkable injection molding compositions and favorably affects the vibrodynamic parameters correlating with the magnitude of the overall heterogeneity of the microstructure of concrete.The results of the research have been tested in the manufacture of prototypes of concrete and reinforced concrete cutting machines (small-sized milling machine), as well as laboratory testing equipment.

Full Text

Restricted Access

About the authors

I. Yu. Lavrov

Penza State University of Architecture and Construction

Author for correspondence.
Email: lavrov0909@gmail.com

Postgraduate Student

Russian Federation, 28, Titova Street, Penza, 440028

V. A. Beregovoy

Penza State University of Architecture and Construction

Email: techbeton@pguas.ru

Doctor of Sciences (Engineering), Professor

Russian Federation, 28, Titova Street, Penza, 440028

References

  1. Kalashnikov V.I., Volodin V.M., Erofeeva I.V., Abramov D.A. Highly efficient self-compacting powder-activated sand concretes and fiber-reinforced concretes. Sovremennye problemy nauki i obrazovaniya. 2015. No. 1–2, pp. 110–117. (In Russian). EDN: TXUWOL
  2. Kalashnikov V.I. Evolution of compositions and strength changes in concretes. Concretes of the present and future. Part 1. Stroitel’nye Materialy [Construction Materials]. 2016. No. 1, pp. 96–103. (In Russian). EDN: VPWHMH
  3. Möhring H.C., Brecher C., Abele E., Fleischer J., Bleicher F. Materials in machine tool structures. CIRP Annals. 2015. Vol. 64, Iss. 2, pp. 725–748. https://doi.org/10.1016/j.cirp.2015.05.005
  4. Kalashnikov V.I., Moskvin R.N., Belyakova E.A. Application of new generation concrete in mechanical engineering. X International Conference «Mechanics, Resource and Diagnostics of Materials and Structures» collection of materials. Ekaterinburg. May 16–20, 2016, pp. 173–174. (In Russian). EDN: VXMBCX
  5. Liang C., Xiao J., Wang Y., Wang C., Mei S. Relationship between internal viscous damping and stiffness of concrete material and structure. Structural Concrete. 2021. Vol. 22. No. 3, pp. 1410–1428. https://doi.org/10.1002/suco.202000628
  6. Ashby M.F. Materials selection in mechanical design. 3rd ed. Oxford (Conn.): Elsevier/Butterworth Heinemann. 2005. 602 p. https://doi.org/10.1016/C2009-0-25539-5
  7. Ansari M., Tartaglione F., Koenke C. Experimental validation of dynamic response of small-scale metaconcrete beams at resonance vibration. Materials. 2023. Vol. 16. Iss. 14, pp. 5029–5045. https://doi.org/10.3390/ma16145029
  8. Carbajo J., Poveda P., Segovia E., Rincón E., Ramis J. Determination of dynamic elastic modulus of materials under a state of simple stresses by using electrodynamic actuators in beam-type mechanical elements. Materials Letters. 2022. Vol. 320. 132383. https://doi.org/10.1016/j.matlet.2022.132383
  9. Macioski G., de Oliveira V., Medeiros M. Strain, natural frequency, damping coefficient and elastic modulus of mortar beams determined by fiber Bragg grating (FBG) sensors. Revista IBRACON de Estruturas e Materiais. 2021. Vol. 14, pp. 1–17. https://doi.org/10.1590/S1983-41952021000300012
  10. Kaewunruen S., Li D., Chen Y., Xiang Z. Enhancement of dynamic damping in eco-friendly railway concrete sleepers using waste-tyre crumb rubber. Materials. 2018. Vol. 11. Iss. 7, pp. 1169–1189. https://doi.org/10.3390/ma11071169
  11. Zhang W., Zeng W., Zhang Y., Yang F., Wu P., Xu G., Gao Y. Investigating the influence of multi-walled carbon nanotubes on the mechanical and damping properties of ultra-high performance concrete. Science and Engineering of Composite Materials. 2020. Vol. 27, pp. 433–444. https://doi.org/10.1515/secm-2020-0046
  12. Travush V.I., Erofeev V.T., Cherkasov V.D., Emelyanov D.V., Erofeeva I.V. Damping properties of cement composites. Promyshlennoe i grazhdanskoe stroitel’stvo. 2018. No. 5, pp. 34–39. (In Russian). EDN: XQZTBB
  13. Lavrov I.Yu., Beregovoy V.A. Laboratory complex for studying vibration dynamic parameters of structural concretes. Regional’naya arkhitektura i stroitel’stvo. 2023. No. 4 (57), pp. 56–65. (In Russian). EDN: FKWUAY. https://doi.org/10.54734/20722958_2023_4_56
  14. Kol’skiy G. Volny napryazheniya v tverdykh telakh [Stress waves in solids]. Moscow: Publishing house of foreign literature. 1955. 192 p.
  15. Lavrov I.Yu., Beregovoy V.A. Compensation of shrinkage deformations of fine-grained concretes for monolithic vibration-loaded structures. Tsement i ego primenenie. 2024. No. 3, pp. 70–75. (In Russian). EDN: UPWBTS

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Fig. 1. Laboratory complex for vibrodynamic testing of concrete by the method of free (a, c) and forced (b, d, e) vibrations

Download (3MB)
Indexing metadata
3. Fig. 2. Algorithm of vibrodynamic tests using the free vibration method

Download (328KB)
Indexing metadata
4. Fig. 3. Effect of cement content on the deformability of concrete: a – kinetics of changes in the static modulus of elasticity of concrete during hardening under normal conditions; b – comparison of the static and dynamic modulus of elasticity after 28 days of normal hardening

Download (251KB)
Indexing metadata
5. Fig. 4. Logarithmic decrement of attenuation of concrete samples with different cement content after 180 days of normal hardening

Download (142KB)
Indexing metadata
6. Fig. 5. Changes in the dynamic characteristics of concrete during the hardening process: a – damping; b – dynamic modulus of elasticity (composition numbers according to Table)

Download (451KB)
Indexing metadata
7. Fig. 6. The fiber used: a, b – steel (general view and microphotograph); c – polypropylene (general view)

Download (959KB)
Indexing metadata
8. Fig. 7. Diagram of the dependence of the damping value on the dynamic modulus of elasticity of fiber-reinforced concrete at different ages

Download (201KB)
Indexing metadata
9. Fig. 8. Characteristics of concrete and concrete mix modified with anti-shrinkage additives

Download (324KB)
Indexing metadata
10. Fig. 9. Shrinkage of concrete with anti-shrinkage additives (after the value reaches a plateau under the specified temperature and humidity conditions)

Download (86KB)
Indexing metadata
11. Fig. 10. Dynamic characteristics of concrete: a – dynamic elastic module; b – logarithmic decrement of attenuation

Download (208KB)
Indexing metadata
12. Fig. 11. Developed processing and testing equipment with concrete base parts: a, b – small-sized CNC milling machine; c – frame of multifunctional viscometer; d, e – tensile testing machine; f – frames of mechanical testing stand

Download (2MB)
Indexing metadata
