Optimization of a logic optical gate on a Y-shaped waveguide combiner

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription or Fee Access

Abstract

Optical logic gates are promising components for building photonic circuits that perform logic operations and calculations. A study was carried out using the method of finite differences in the time domain (FDTD) of a logic valve based on a Y-shaped waveguide adder that performs the functions NOT, OR, exclusive OR. Based on the results of the study, the configuration of the Y-shaped adder was optimized, which provides an attenuation coefficient (contrast) of the order of 35.4 dB between logical "1" and "0" with a signal transmission delay time to the output port of 0.33 ps. The possibility of implementing a cascade scheme for the NAND function with a contrast ratio of about 34 dB and a transmission time delay of 0.73 ps is considered. The proposed design of the logic gate can potentially be used in the development of photonic circuits on a chip to increase their speed and efficiency.
