Two-Dimensional Inversion of Magnetotelluric Data in the Study of Three-Dimensional Media

Capa

Citar

Texto integral

Acesso aberto Acesso aberto
Acesso é fechado Acesso está concedido
Acesso é fechado Acesso é pago ou somente para assinantes

Resumo

A three-dimensional geoelectric model of the tectonosphere has been constructed, containing typical geoelectric heterogeneities at three structural levels: the uplift and depression of the basement roof, conductive prisms in the consolidated crust, and the asthenospheric uplift in the upper mantle. Synthetic magnetotelluric data have been calculated and their sensitivity to geoelectric structures has been analyzed. A two-dimensional smoothing inversion of the synthetic data has been performed along two perpendicular profiles. Despite significant three-dimensional effects, the position of the basement roof has been reconstructed quite accurately in the obtained sections, rough images of crustal structures have been obtained, and the mantle structure is poorly resolved. The influence of random noise of various levels on the inversion results has been estimated. In the future, a three-dimensional inversion of the synthetic data is planned.
