Sulfur isotopic composition of sulfides and sulphates from rocks of carbonatite complexes of the devonian Kola alkaline province

Cover Page

Cite item

Full Text

Abstract

This study presents the sulfur isotopic characteristics in baryte from carbonatites of the Sallanlatva massif and sulfides (mainly pyrite and pyrrhotite) from carbonatites, phoscorites and products of their contact interaction with the host silicate rocks of most carbonatite-bearing complexes of the Devonian Kola Alkaline Province (KAP). For some complexes (Ozernaya Varaka, Kontozero), these characteristics are reported for the first time. The determined range of δ34S variations of sulfides in one complex does not exceed 4‰, but reaches 20‰ for the entire Kola Alkaline Province. This may be related to the evolution style of carbonatites and associated rocks. It is shown that the δ34S value in sulfides decreases from (1) the least evolved volcanic carbonatites of the Kontozero complex (δ34Savg. = –1.3‰) through (2) carbonatites and phoscorites of the Kovdor, Ozernaya Varaka, Sokli, and Salmagora massifs towards (3) the rocks of Seblyavr, Vuoriyarvi, and, finally, the carbonatites of Sallanlatva (δ34Savg. = –14.7‰) massifs, where sulfides differ from those of other KAP carbonatites in their exceptionally low δ34S values. The carbonatite volcanics of Kontozero are almost barren of REE mineralization; carbonatites of the second group contain accessory amounts of REE minerals; the third group is peculiar in the abundance of late carbonatites, where REE carbonates are frequently major minerals. Thus, the greater the volume of REE minerals in carbonatites of the complex, the lower the δ34S value in sulfides from its carbonatites and associated rocks. For the first time in the KAP, the sulfur isotopic composition of associated baryte–pyrite pairs was studied in the Sallanlatva carbonatites. The sulfur isotopic characteristics are shown to correspond to the final low-temperature (250–350°C) stage of carbonatite evolution in oxidized conditions, which satisfies the parameters of baryte crystallization. Since the studied samples of the Sallanlatva carbonatites are explosive breccias, the oxidized composition of fluids may indicate their phreatomagmatic nature, i.e., formation due to the interaction of intruded hot matter (melt/fluid) with meteoric waters.

About the authors

E. N. Kozlov

Geological Institute, Kola Science Centre of the Russian Academy of Sciences (GI KSC RAS)

Author for correspondence.
Email: kozlov_e.n@mail.ru
Russian Federation, Apatity, 184209

E. N. Fomina

Geological Institute, Kola Science Centre of the Russian Academy of Sciences (GI KSC RAS)

Email: kozlov_e.n@mail.ru
Russian Federation, Apatity, 184209

V. N. Reutsky

V.S. Sobolev Institute of Geology and Mineralogy, Siberian Branch of the Russian Academy of Sciences (IGM SB RAS)

Email: kozlov_e.n@mail.ru
Russian Federation, Novosibirsk, 630090

M. Yu. Sidorov

Geological Institute, Kola Science Centre of the Russian Academy of Sciences (GI KSC RAS)

Email: kozlov_e.n@mail.ru
Russian Federation, Apatity, 184209

References

  1. Афанасьев Б.В. (2011) Минеральные ресурсы щелочно-ультраосновных массивов Кольского полуострова. СПб: Изд-во «Роза ветров», 224 с.
  2. Баталева Ю.В., Фурман О.В., Борздов Ю.М., Пальянов Ю.Н. (2023) Экспериментальное исследование растворимости серы в Ca, Mg-карбонатном расплаве при Р, Т-параметрах литосферной мантии. Геология и геофизика 64 (4), 479–493.
  3. Дубинина Е.О., Морозова А.С., Расс И.Т., Авдеенко А.С. (2023) Изотопное фракционирование кислорода в системе силикат–карбонат при формировании пород массива Ковдор (Кольский п-ов). ДАН. Науки о Земле 512 (2), 212–218.
  4. Никифоров А.В., Болонин А.В., Покровский Б.Г., Сугоракова А.М., Чугаев А.В., Лыхин Д.А. (2006) Геохимия изотопов (О, С, S, Sr) И Rb-Sr-возраст карбонатитов центральной Тувы. Геология рудных месторождений 48 (4), 296–319.
  5. Покровский Б.Г. (2000) Коровая контаминация мантийных магм по данным изотопной геохимии. М.: Наука, 228 с.
  6. Arzamastsev A.A., Glaznev V.N., Arzamastseva L.V., Bea F., Montero P. (2001) Kola alkaline province in the Paleozoic: evaluation of primary mantle magma composition and magma generation conditions. Russ. J. Earth Sci. 3 (1), 1–32.
  7. Barker D.S. (2001) Calculated silica activities in carbonatite liquids. Contrib. Mineral. Petrol. 141 (6), 704–709.
  8. Bell K., Rukhlov A.S. (2004) Carbonatites from the Kola Alkaline Province: origin, evolution and source characteristics. Phoscorites and carbonatites from mantle to mine: the key example of the Kola alkaline province (Eds. Wall F., Zaitsev A.N.). London: Mineralogical Society of Great Britain & Ireland, 433–468.
  9. Bell K., Zaitsev A.N., Spratt J., Fröjdö S., Rukhlov A.S. (2015) Elemental, lead and sulfur isotopic compositions of galena from Kola carbonatites, Russia — implications for melt and mantle evolution. Mineral. Mag. 79 (2), 219–241.
  10. Bulakh A.G., Ivanikov V.V., Orlova M.P. (2004) Overview of carbonatite-phoscorite complexes of the Kola Alkaline Province in the context of a Scandinavian North Atlantic Alkaline Province. Phoscorites and carbonatites from mantle to mine: the key example of the Kola alkaline province (Eds. Wall F., Zaitsev A.N.). London: Mineralogical Society of Great Britain & Ireland, 1–43.
  11. Burgisser A., Scaillet B. (2007) Redox evolution of a degassing magma rising to the surface. Nature 445 (7124), 194–197.
  12. Cangelosi D., Smith M., Banks D., Yardley B. (2019) The role of sulfate-rich fluids in heavy rare earth enrichment at the Dashigou carbonatite deposit, Huanglongpu, China. Mineral. Mag. 84 (1), 65–80.
  13. Cui H., Zhong R., Xie Y., Wang X., Chen H. (2021) Melt–Fluid and Fluid–Fluid Immiscibility in a Na2SO4–SiO2–H2O System and Implications for the Formation of Rare Earth Deposits. Acta Geol. Sin. (Engl. Ed.) 95 (5), 1604–1610.
  14. Cui H., Zhong R., Xie Y., Yuan X., Liu W., Brugger J., Yu C. (2019) Forming sulfate- and REE-rich fluids in the presence of quartz. Geology 48 (2), 145–148.
  15. Demény A., Sitnikova M.A., Karchevsky P.I. (2004) Stable C and O isotope compositions of carbonatite complexes of the Kola Alkaline Province: phoscorite-carbonatite relationships and source compositions. Phoscorites and carbonatites from mantle to mine: the key example of the Kola alkaline province (Eds. Wall F., Zaitsev A.N.). London: Mineralogical Society of Great Britain & Ireland, 407–431.
  16. Dowman E., Wall F., Treloar P.J., Rankin A.H. (2017) Rare-earth mobility as a result of multiple phases of fluid activity in fenite around the Chilwa Island Carbonatite, Malawi. Mineral. Mag. 81 (6), 1367–1395.
  17. Downes H., Balaganskaya E., Beard A., Liferovich R., Demaiffe D. (2005) Petrogenetic processes in the ultramafic, alkaline and carbonatitic magmatism in the Kola Alkaline Province: A review. Lithos 85 (1–4), 48–75.
  18. Drüppel K., Hoefs J., Okrusch M. (2005) Fenitizing Processes Induced by Ferrocarbonatite Magmatism at Swartbooisdrif, NW Namibia. J. Petrol. 46 (2), 377–406.
  19. Dunworth E.A., Bell K. (2001) The Turiy Massif, Kola Peninsula, Russia: Isotopic and geochemical evidence for multi-source evolution. J. Petrol. 42 (2), 377–406.
  20. Fifarek R.H., Rye R.O. (2005) Stable-isotope geochemistry of the Pierina high-sulfidation Au–Ag deposit, Peru: influence of hydrodynamics on SO42––H2S sulfur isotopic exchange in magmatic-steam and steam-heated environments. Chem. Geol. 215 (1–4), 253–279.
  21. Fomina E., Kozlov E., Bazai A. (2020) Factor Analysis of XRF and XRPD Data on the Example of the Rocks of the Kontozero Carbonatite Complex (NW Russia). Part I: Algorithm. Crystals 10 (10), 874.
  22. Fomina E.N., Kozlov E.N. (2021) Stable (C, O) and radiogenic (Sr, Nd) isotopic evidence for REE-carbonatite formation processes in Petyayan-Vara (Vuoriyarvi massif, NW Russia). Lithos 398–399, 106282.
  23. Giebel R.J., Gauert C.D.K., Marks M.A.W., Costin G., Markl G. (2017) Multi-stage formation of REE minerals in the Palabora Carbonatite Complex, South Africa. Am. Mineral. 102 (6), 1218–1233.
  24. Gomide C.S., Brod J.A., Junqueira-Brod T.C., Buhn B.M., Santos R.V., Barbosa E.S.R., Cordeiro P.F.O., Palmieri M., Grasso C.B., Torres M.G. (2013) Sulfur isotopes from Brazilian alkaline carbonatite complexes. Chem. Geol. 341, 38–49.
  25. Goodenough K.M., Wall F., Merriman D. (2018) The Rare Earth Elements: Demand, Global Resources, and Challenges for Resourcing Future Generations. Nat. Resour. Res. 27 (2), 201–216.
  26. Han L., Tanweer A., Szaran J., Halas S. (2002) A Modified Technique for the Preparation of SO2 from Sulphates and Sulphides for Sulphur Isotope Analyses. Isot. Environ. Health Stud. 38 (3), 177–183.
  27. Helz G.R., Wyllie P.J. (1979) Liquidus relationships in the system CaCO3–Ca(OH)2–CaS and the solubility of sulfur in carbonatite magmas. Geochim. Cosmochim. Acta 43 (2), 259–265.
  28. Huber M., Mokrushin A.V. Sulfur isotope signatures of sulfides from the Khibina and Lovozero massifs (Kola Alkaline Province, Fennoscandian Shield). Vestnik of MSTU 24 (1), 80–87.
  29. Hutchison W., Babiel R.J., Finch A.A., Marks M.A.W., Markl G., Boyce A.J., Stüeken E.E., Friis H., Borst A.M., Horsburgh N.J. (2019) Sulphur isotopes of alkaline magmas unlock long-term records of crustal recycling on Earth. Nat. Commun. 10, 4208.
  30. Hutchison W., Finch A.A., Boyce A.J. (2020) The sulfur isotope evolution of magmatic-hydrothermal fluids: insights into ore-forming processes. Geochim. Cosmochim. Acta 288, 176–198.
  31. Jugo P.J., Luth R.W., Richards J.P. (2005) An Experimental Study of the Sulfur Content in Basaltic Melts Saturated with Immiscible Sulfide or Sulfate Liquids at 1300 °C and 1.0 Gpa. J. Petrol. 46 (4), 783–798.
  32. Kokh M.A., Assayag N., Mounic S., Cartigny P., Gurenko A., Pokrovski G.S. (2020) Multiple sulfur isotope fractionation in hydrothermal systems in the presence of radical ions and molecular sulfur. Geochim. Cosmochim. Acta 285, 100–128.
  33. Kozlov E., Fomina E., Sidorov M., Shilovskikh V., Bocharov V., Chernyavsky A., Huber M. (2020) The Petyayan-Vara Carbonatite-Hosted Rare Earth Deposit (Vuoriyarvi, NW Russia): Mineralogy and Geochemistry. Minerals 10 (1), 73.
  34. Kozlov E., Skiba V., Fomina E., Sidorov M. (2021) Noble gas isotopic signatures of sulfides in carbonatites of the Vuoriyarvi alkaline-ultrabasic complex (Kola Region, NW Russia). Arab. J. Geosci. 14, 1725.
  35. Kramm U. (1993) Mantle components of carbonatites from the Kola Alkaline Province, Russia and Finland: A Nd–Sr study. Eur. J. Mineral. 5 (5), 985–990.
  36. Kramm U., Kogarko L.N., Kononova V.A., Vartiainen H. (1993) The Kola Alkaline Province of the CIS and Finland: Precise Rb–Sr ages define 380–360 Ma age range for all magmatism. Lithos 30 (1), 33–44.
  37. Lee M., Lee J., Hur S., Kim Y., Moutte J., Balaganskaya E. (2006) Sr–Nd–Pb isotopic compositions of the Kovdor phoscorite–carbonatite complex, Kola Peninsula, NW Russia. Lithos 91 (1–4), 250–261.
  38. Liu S., Fan H.-R., Yang K.-F., Hu F.-F., Wang K.-Y., Chen F.-K., Yang Y.-H., Yang Z.-F., Wang Q.-W. (2018) Mesoproterozoic and Paleozoic hydrothermal metasomatism in the giant Bayan Obo REE-Nb-Fe deposit: Constrains from trace elements and Sr-Nd isotope of fluorite and preliminary thermodynamic calculation. Precambrian Res. 311, 228–246.
  39. Mäkelä M., Vartiainen H. (1978) A study of sulfur isotopes in the Sokli multi-stage carbonatite (Finland). Chem. Geol. 21 (3–4), 257–265.
  40. Mitchell R.H., Krouse H.R. (1975) Sulphur isotope geochemistry of carbonatites. Geochim. Cosmochim. Acta 39 (11), 1505–1513.
  41. Ohmoto H., Lasaga A.C. (1982) Kinetics of reactions between aqueous sulfates and sulfides in hydrothermal systems. Geochim. Cosmochim. Acta 46 (10), 1727–1745.
  42. Prokopyev I., Kozlov E., Fomina E., Doroshkevich A., Dyomkin M. (2020) Mineralogy and Fluid Regime of Formation of the REE-Late-Stage Hydrothermal Mineralization of Petyayan-Vara Carbonatites (Vuoriyarvi, Kola Region, NW Russia). Minerals 10 (5), 405.
  43. Ruberti E., Enrich G.E.R., Gomes C.B., Comin-Chiaramonti P. (2008) Hydrothermal REE fluorocarbonate mineralization at Barra do Itapirapuã, a multiple stockwork carbonate, southern Brazil. Can. Mineral. 46 (4), 901–914.
  44. Rye R.O. (2005) A review of the stable-isotope geochemistry of sulfate minerals in selected igneous environments and related hydrothermal systems. Chem. Geol. 215 (1–4), 5–36
  45. Schauble E.A. (2004) Applying Stable Isotope Fractionation Theory to New Systems. Rev. Mineral. Geochem. 55 (1), 65–111.
  46. Seal R.R. (2006) Sulfur Isotope Geochemistry of Sulfide Minerals. Rev. Mineral. Geochem. 61 (1), 633–677.
  47. Smith M., Kynicky J., Xu C., Song W., Spratt J., Jeffries T., Brtnicky M., Kopriva A., Cangelosi D. (2018) The origin of secondary heavy rare earth element enrichment in carbonatites: Constraints from the evolution of the Huanglongpu district, China. Lithos 308–309, 65–82.
  48. Smith M.P., Campbell L.S., Kynicky J. (2015) A review of the genesis of the world class Bayan Obo Fe–REE–Nb deposits, Inner Mongolia, China: Multistage processes and outstanding questions. Ore Geol. Rev. 64, 459–476.
  49. Song W., Xu C., Smith M.P., Kynicky J., Huang K., Wei C., Zhou L., Shu Q. (2016) Origin of unusual HREE-Mo-rich carbonatites in the Qinling orogen, China. Sci. Rep. 6, 1–10.
  50. Tolstikhin I.N., Kamensky I.L., Marty B., Nivin V.A., Vetrin V.R., Balaganskaya E.G., Ikorsky S.V., Gannibal M.A., Weiss D., Verhulst A., Demaiffe D. (2002) Rare gas isotopes and parent trace elements in ultrabasic-alkaline-carbonatite complexes, Kola Peninsula: identification of lower mantle plume component. Geochim. Cosmochim. Acta 66 (5), 881–901.
  51. Verhulst A., Balaganskaya E., Kirnarsky Y., Demaiffe D. (2000) Petrological and geochemical (trace elements and Sr–Nd isotopes) characteristics of the Paleozoic Kovdor ultramafic, alkaline and carbonatite intrusion (Kola Peninsula, NW Russia). Lithos 51 (1–2), 1–25.
  52. Wall F. (2013) Rare earth elements. Critical Metals Handbook (Ed. Gunn G.). Oxford: John Wiley & Sons. 312–339.
  53. Wall F., Zaitsev A.N. (2004) Rare earth minerals in Kola carbonatites. Phoscorites and carbonatites from mantle to mine: the key example of the Kola alkaline province (Eds. Wall F., Zaitsev A.N.). London: Mineralogical Society of Great Britain & Ireland, 341–373.
  54. Walter B.F., Giebel R.J., Siegfried P.R., Gudelius D., Kolb J. (2023) The eruption interface between carbonatitic dykes and diatremes — The Gross Brukkaros volcanic field Namibia. Chem. Geol. 621, 121344.
  55. Wan Y., Wang X., Chou I.-M., Li X. (2021). Role of sulfate in the transport and enrichment of REE in hydrothermal systems. Earth Planet. Sci. Lett. 569, 117068.
  56. Wu F.-Y., Arzamastsev A.A., Mitchell R.H., Li Q.-L., Sun J., Yang Y.-H., Wang R.-C. (2013) Emplacement age and Sr–Nd isotopic compositions of the Afrikanda alkaline ultramafic complex, Kola Peninsula, Russia. Chem. Geol. 353, 210–229.
  57. Xie Y., Li Y., Hou Z., Cooke D.R., Danyushevsky L., Dominy S.C., Shuping Yin (2015) A model for carbonatite hosted REE mineralisation — the Mianning–Dechang REE belt, Western Sichuan Province, China. Ore Geol. Rev. 70, 595–612
  58. Yaxley G.M., Anenburg M., Tappe S., Decree S., Guzmics T. (2022) Carbonatites: Classification, Sources, Evolution, and Emplacement. Annu. Rev. Earth Planet. Sci. 50 (1), 261–293.
  59. Yongfei Z. (1990) Sulfur isotope fractionation in magmatic systems: Models of Rayleigh distillation and selective flux. Chin. J. Geochem. 9 (1), 27–45.
  60. Zaitsev A., Bell K. (1995) Sr and Nd isotope data of apatite, calcite and dolomite as indicators of source, and the relationships of phoscorites and carbonatites from the Kovdor massif, Kola peninsula, Russia. Contrib. Mineral. Petrol. 121 (3), 324–335.
  61. Zaitsev A.N. (1996) Rhombohedral carbonates from carbonatites of the Khibina Massif, Kola Peninsula, Russia. Can. Mineral. 34 (2), 453–468.
  62. Zaitsev A.N., Demény A., Sindern S., Wall F. (2002) Burbankite group minerals and their alteration in rare earth carbonatites — source of elements and fluids (evidence from C–O and Sr–Nd isotopic data). Lithos 62 (1–2), 15–33.
  63. Zaitsev A.N., Terry Williams C., Jeffries T.E., Strekopytov S., Moutte J., Ivashchenkova O.V., Spratt J., Petrov S.V., Wall F., Seltmann R., Borozdin A.P. (2014) Rare earth elements in phoscorites and carbonatites of the Devonian Kola Alkaline Province, Russia: Examples from Kovdor, Khibina, Vuoriyarvi and Turiy Mys complexes. Ore Geol. Rev. 61, 204–225.
  64. Zhang W., Chen W.T., Mernagh T.P., Zhou L. (2021) Quantifying the nature of ore-forming fluids in the Dalucao carbonatite-related REE deposit, Southwest China: implication for the transport and deposition of REEs. Miner. Deposita 57 (6), 935–953.
  65. Zhang Y., Liu Y., Hou Z., Zheng X. (2021a) Iron and sulfur isotopic compositions of carbonatite-related REE deposits in the Mianning–Dechang REE belt, China: Implications for fluid evolution. Ore Geol. Rev. 138, 104373.
  66. Zheng X., Liu Y., Zhang L. (2021) The role of sulfate-, alkali-, and halogen-rich fluids in mobilization and mineralization of rare earth elements: Insights from bulk fluid compositions in the Mianning–Dechang carbonatite-related REE belt, southwestern China. Lithos 386–387, 106008.
