Specifics of the Development of an On-Board Visualization System for Civil Aircrafts

封面

如何引用文章

全文:

开放存取 开放存取
受限制的访问 ##reader.subscriptionAccessGranted##
受限制的访问 订阅存取

详细

The instrument panels of modern aircraft are created using the “glass cockpit” concept. This new interface philosophy improves the perception of important flight information by displaying it on a single multi-function display. The paper considers the problems that arise when developing a certified pilot display visualization system designed for operation on civil aircraft under the Russian real-time operating system JetOS. The paper presents several algorithmic solutions that allow achieving acceptable visualization speed. In particular, a solution to the problem of rigid scheduling of operating system partitions is described in detail. This solution allows to overcome the degradation of rendering speed. Directions for further work have been outlined.
