Email this article Methodology of frequency resource utilization in the design of railway LTE-1800 TDD standard radio communications
- Authors: Lobeev D.P.1
-
Affiliations:
- Петербургский государственный университет путей сообщения Императора Александра I
- Issue: No 4 (2025)
- Pages: 58-68
- Section: WIRELESS COMMUNICATION
- URL: https://journals.eco-vector.com/2070-8963/article/view/686815
- DOI: https://doi.org/10.22184/2070-8963.2025.128.4.58.68
- ID: 686815
Cite item
Open Access
Access granted
Abstract
When designing a digital network of technological railway radio communication based on the LTE-1800 TDD standard, as well as during frequency-territorial planning, the most relevant tasks are the use of frequency resource and ensuring electromagnetic compatibility (EMC) of the system. The paper considers the topical aspects of network construction and proposes a variant of frequency resource utilisation for railway transport taking into account EMC.
Full Text
About the authors
D. P. Lobeev
Петербургский государственный университет путей сообщения Императора Александра I
Author for correspondence.
Email: mladkevich@mail.ru
аспирант кафедры "Электрическая связь"
Russian FederationReferences
- Тараненко А.Ю., Гриценко А.А., Лобеев Д.П. Оптимизация использования частотного спектра // Автоматика. Связь. Информатика. 2025 № 1. С. 9–12.
- Решение ГКРЧ при Минкомсвязи России от 11.09.2018 № 18-46-02 (с изм. от 23.12.2022) "О выделении полосы радиочастот 1785−1805 МГц для радиоэлектронных средств сухопутной подвижной службы для создания технологических сетей связи на железнодорожном транспорте.
- ГОСТ 33973-2016. Межгосударственный стандарт. Железнодорожная электросвязь. Поездная радиосвязь. Технические требования и методы контроля. М.: Стандартинформ, 2017.
- Скрынников В.Г. Радиоподсистемы UMTS/LTE. Теория и практика. М.: Спорт и Культура−2000, 2012. 864 c.
- ПНСТ 828-2023. Предварительный национальный стандарт Российской Федерации. Устройства и системы электросвязи для систем управления железнодорожным подвижным составом в автоматическом и дистанционном режимах. Общие технические требования. М.: Российский институт стандартизации, 2023.
- TS 122 289-V17.0.0 LTE; 5G; Mobile communication system for railways (3GPP TS 22.289 version 17.0.0 Release 17). ETSI, 2022. 19 p.
- Физический уровень сетей LTE [Электронный ресурс]. URL: https://1234g.ru/4g/lte/fizicheskij-uroven-standarta-lte/fizicheskij-uroven-setej-lte (дата обращения 18.01.2025).
- LTE The UMTS Long Term Evolution: From Theory to Practice. 2nd edition. John Wiley & Sons, 2011. 792 p.
