INTRODUCTION

Currently, researchers are paying increasing attention to the surgical treatment of adenomyosis. This is because of the effectiveness of this approach for correcting the symptoms of the disease and the ability to preserve reproductive function. Hysterectomy was traditionally considered to be the operation of choice for adenomyosis, but taking into account the large number of patients of reproductive age who desire to retain their reproductive function, this operation cannot be considered optimal for either patients or surgeons. This has led to the emergence and significant spread of new approaches for the surgical treatment of adenomyosis, such as organ-preserving surgical interventions.

It is important to keep in mind that organ-preserving surgery does not cure the patient of adenomyosis and is aimed at reducing pain; eliminating abnormal uterine, heavy menstrual, or intermenstrual bleeding; and restoring reproductive function.

When choosing a method of treatment, it is necessary to keep in mind that almost all surgical procedures for endometriosis are technically difficult, may be accompanied by increased blood loss, and may increase the risk of uterine rupture during subsequent pregnancy.

When performing surgery in patients with adenomyosis, the following general recommendations can be considered:

1. When the uterus is large, it is advisable to use anterolateral optics (“angled” or “oblique”), which allows better visualization of small pelvic and retroperitoneal structures. The “high” positioning of the optical and working trocars is also effective. The trocars should be offset vertically at the same distance in proportion to the size of the enlarged uterus.
2. The use of a uterine manipulator allows convenient work in both the Douglas and parametral spaces. Depending on the size of the cervix and uterine cavity, the length of the uterine manipulator nozzle should be chosen. When working with a short nozzle, the manipulator does not fix to the uterus; therefore, it becomes difficult to displace the uterus intraoperatively.
3. The uterine tissue affected by adenomyosis from the abdominal cavity is most often removed by morcellation in a container, according to modern concepts.
4. Other forms of endometrioid disease (ovarian cysts, and deep infiltrative and peritoneal endometriosis), as well as adhesions of abdominal and pelvic organs should be considered.

Currently, in clinical practice, adenomyosis is often divided into the following two phenotypes: external (when the outer layers of the myometrium are affected) and internal (when the muscular wall closer to the endometrium is affected). It has been shown that the manifestations of the disease differ among patients, and external adenomyosis is more often associated with endometriosis, especially with its deep infiltrative form [1].

The most common indications for surgical intervention are as follows:

• Menstrual cycle disorders involving abnormal uterine, heavy menstrual, and intermenstrual bleeding;
• Pain syndrome (dysmenorrhea, chronic pelvic pain, and dyspareunia) with ineffective conservative therapy;
• Infertility associated with adenomyosis;
• Large uterine size (more than 12 weeks) or rapid growth (more than 4 weeks per year).

Before surgical intervention, hormonal therapy for preoperative preparation is indicated in some patients. Gonadotropin-releasing hormone agonists, gestagens, progesterone receptor modulators, and antiprogestagens (mifepristone) are most commonly used. In some cases, antianemic therapy and hemostatic agents are recommended for certain indications.

The goals of such preparation are to improve the outcomes of the planned intervention and reduce the numbers of intraoperative and postoperative complications, and hemotransfusions. Preoperative preparation can help to correct anemia, reduce uterine size, and, consequently, reduce the amount of intraoperative blood loss and the surgical intervention time. It also provides an opportunity to choose the optimal time for the surgical intervention. The planned surgical procedure can be performed using different surgical approaches, such as hysteroscopy, laparoscopy, and laparotomy.

The possibilities of performing the surgery itself and the surgical volume in adenomyosis directly depend on the form of the disease. At present, diffuse, focal, nodular, cystic, and sclerotic disease forms are commonly distinguished [2]. It should be kept in mind that the forms can often be combined.

The most common local forms of adenomyosis involve nodes, cysts, and areas of sclerosis in the myometrium without clear boundaries with the surrounding tissues.

In the cystic form, the diagnosis is mainly made on the basis of the magnetic resonance imaging findings of a cystic structure with an internal diameter of 10 mm or more and hemorrhagic content surrounded by myometrial tissue. The size and localization of the cyst in relation to the uterine cavity can be crucial in the choice of the surgical intervention. In the classification of Brosens et al., three subtypes of adenomyosis cysts were identified based on their locations in the uterine wall [3].

HYSTEROSCOPY FOR ADENOMYOSIS

Hysteroscopy for adenomyosis is performed routinely for the following reasons:

1. Visual assessment of the uterine cavity and detection of intrauterine pathology. It should be kept in mind that adenomyosis can reveal different lesion patterns, including visible mouths (“passages” of adenomyosis) (Figure 1), sclerotic changes and synechiae, and diffuse myometrial changes (a “cobblestone sidewalk” appearance).
2. Verification of the diagnosis. For morphological diagnosis, a trepan biopsy of the myometrium in the area of the uterine floor can be performed using a special needle (preferably from 3–5 points to improve diagnosis), or a section of the altered myometrium can be obtained using an electroloop. If the patient has abnormal uterine or heavy menstrual bleeding, hysteroscopy can be supplemented by obligatory histological examination of the endometrium. A targeted biopsy is sufficient to minimize trauma to the uterine walls. Curettage of the uterine cavity is possible only in cases of endometrial hyperplasia.
3. Surgical treatment of the cystic form of adenomyosis. When cysts are close to the uterine cavity, hysteroscopic access allows opening and drainage of cystic cavities and coagulation of their inner walls. Such a surgery can be sufficient to significantly alleviate pain and reduce the volume of menstrual blood loss.



Fig. 1. Uterine cavity with adenomyosis foci



To open cysts of the uterine wall immediately adjacent to the uterine cavity, the scissors in a BiOH or BETTOCCHI hysteroscope, a bipolar cutting hook, or a loop in the case of a hysteroresectoscope can be used.

Technically, the surgery is performed as follows. On the side of the uterine cavity, the uterine wall is dissected under ultrasound guidance at the region closest to the cystic wall. The cystic cavity is widely opened and washed with saline solution. Then, the inner lining of the cyst is coagulated using a bipolar electrode or laser energy.

LAPAROSCOPY AND LAPAROTOMY FOR ADENOMYOSIS

Organ-preserving surgeries are performed for the following:

• Removal of a node of adenomyosis;
• Removal of a cyst (cystic form);
• Adenomyomectomy (partial or complete) for the diffuse form of adenomyosis.

Adenomyosis nodal dissection can be performed by wedge resection or by a technique similar to myomectomy, but with less differentiation of the border between the nodule and intact myometrium (Figure 2). The surgeon should rely on preoperative ultrasound or magnetic resonance imaging and the appearance of the uterine wall for tissue separation.



Fig. 2. Uterus with adenomyosis



The uterine incision can be made using ultrasound and monopolar energy, or the uterine wall can be dissected with scissors. After dissecting the myometrium, the adenomyosis node is released from the surrounding tissue (Figure 3). This is the most difficult stage of the operation. In addition to technical difficulties, such as the absence of a clear boundary between the tissues to be separated and difficulties in separating the node from the uterine wall, increased tissue bleeding and associated impaired visualization can occur. Temporary occlusion of the uterine arteries by clipping can be performed to reduce intraoperative blood loss in patients with extensive uterine lesions.



Fig. 3. Removal of the adenomyosis node



Our own experience shows that ultrasound energy is the most appropriate for this stage of surgery, as it minimizes charring, thermal trauma to surrounding tissues, and smoke in the abdominal cavity. The node is seized with a rigid clamp or forceps and pulled from the surrounding tissues, and the vessels and bundles of connective tissue and muscle fibers going to the node are coagulated and crossed with an ultrasound scalpel and bipolar clamp. The node is removed, and subsequently, the large bleeding vessels in the node bed are coagulated. There is no need to coagulate the entire surface of the node bed, as the vessels in this area will provide vascularization and aid in the complete repair of the forming uterine scar.

The uterine wall defect is then sutured with absorbable suture material. For this purpose, separate Vicryl and Monocryl sutures are used to suture the uterine wound in several rows, with the deepest sutures being muscular-muscular and the superficial ones being muscular-serous, which coincides with the technique described by Tjkgoz et al. [4].

Accurate suturing of the uterine wound is essential for the formation of a complete scar (Figure 4). Care must be taken to suture the very “bottom” of the uterine wound and the entire myometrial defect. The cavities left behind can cause hematoma formation in the uterine wall, with subsequent uterine wall pseudocyst formation in the remote postoperative period. After suturing the uterine wall, it is advisable to place an antispastic barrier on the uterus.



Fig. 4. Uterus after removal of the adenomyosis node and suturing



The adenomyosis node is morcellated, removed from the abdominal cavity, and sent for histological examination.

In cavity surgeries for the cystic form of adenomyosis, a similar intervention technique is used. It should be noted that it is almost never possible to remove an adenomyosis cyst without opening its cavity. This is because of the dense ingrowth of the cyst wall into intact myometrium and the thin wall of the cyst itself [5]. The cyst should be slowly and carefully extracted from the surrounding tissues, trying to maintain the integrity of the cyst as long as possible. This technique not only prevents the entry of endometrioid cells into healthy tissues, but also makes it technically easier to remove the tumor. When the cavity is opened, the cavity and surrounding tissues should be thoroughly washed and the surgery should be continued. Particular attention should be paid to the complete excision of all cystic walls. Leaving altered tissue is a significant risk factor for recurrence of the disease.

When performing adenomyomectomy for the nodular form of adenomyosis, it is advisable to use double-flap suturing to close the defect to avoid tissue tension and to achieve sufficient thickness of the uterine wall.

In the diffuse form of adenomyosis and extensive adenomyosis, adenomyomectomy with three-flap metaplasty proposed by Osada can be used with laparotomy access [6].

The surgical procedure consists of radical adenomyosis removal, leaving 1 cm of tissue above the endometrium and 1 cm of tissue below the serous membrane, followed by reconstruction of the uterus with a triple flap. To prevent bleeding during the procedure, a turnstile in the form of a 6 mm wide rubber tube placed around the proximal part of the cervix is used. The uterus is first dissected in half in the mid-sagittal direction until the uterine cavity is reached. Adenomyotic tissue is removed, and the myometrium is 10 mm away from the serous layer and the endometrium. The endometrium is closed. On one side of the uterus, the muscular and serous membranes are sutured anteriorly and posteriorly. The serosacral-muscular layer of the opposite side of the uterus is then brought in. The advantage of this method is the possibility of a wider and more thorough excision of the affected tissue and accessibility for any uterine size. After a wide excision of the affected area, the use of three layers of myometrium allows the reconstruction of the uterine wall with sufficient thickness to reduce the risk of uterine rupture in a future pregnancy.

Although adenomyosis is a chronic and progressive disease, relapse is rare with this technique.

The literature describes surgeries involving two- and three-lobed methods of suturing the uterine wall defect, but at present, they are more of historical interest.

For the diffuse form of adenomyosis, surgery involving a four-flap technique using laparoscopic access is also widespread. A cruciform incision is made in the fundus of the uterus and the uterine wall is dissected in the longitudinal and transverse directions. These incisions are made as deep as the uterine cavity, but without opening it. The depth of the incision is planned in advance based on ultrasound or pelvic magnetic resonance imaging findings and is controlled visually during surgery [7]. Next, the isolated flap is grasped with a rigid clamp by the outer part of the wall and serous membrane, and the affected myometrium is excised from the serous membrane of the uterus, leaving smooth muscle tissue on the serosa with a thickness of about 5 mm. This technique is performed consecutively with each of the flaps. After this, the intact uterine cavity, myometrium with a thickness of about 5 mm on the endometrium, and serous membrane dissected with a cruciform incision are left. To suture the defects and form the uterine wall, the most expedient approach is to place individual sutures with capture of the bottom of the wound.

The external and internal parts of the uterine wall are well matched so that they fit tightly together. Sutures are not inserted into the uterine cavity, and it remains intact in relation to the myometrium.

In order to minimize intraoperative blood loss during laparoscopic access, temporary uterine artery clipping can be performed. The final results of the surgery include the removal of pathologically altered tissues and a significant reduction in uterine volume.

The clinical effects of these surgeries are manifested by a decrease in pain and a decrease in menstrual blood loss, and in some cases, fertility is restored.

After surgery, a number of authors recommend the use of gonadotropin-releasing hormone agonists for 3 months.

PREGNANCIES AFTER ORGAN-PRESERVING SURGERY FOR ADENOMYOSIS

The pregnancy rate in patients with stage III–IV adenomyosis does not exceed 10%–15%, since none of the treatments can create favorable conditions for embryo implantation [8].

Reproductive function was evaluated in 137 patients with diffuse adenomyosis who underwent adenomyomectomy with double-flap metroplasty from January 2011 to December 2019 [9, 10]. The indications for the surgery were infertility and severe dysmenorrhea. After the surgery, 56 patients (40.9%) became pregnant (62 pregnancies, including 35 natural pregnancies and 27 pregnancies with the use of assisted reproductive technologies).

The data from a study of Korean surgeons that presented the pregnancy outcomes in 22 patients are also noteworthy. The women underwent adenomyomectomy with transient uterine artery occlusion. The mean age of the pregnant women was 37.0 years (standard deviation [SD], 3.1 years; range, 32–45 years; median, 37 years). All patients underwent cesarean section for delivery. The mean gestational age was 36.2 weeks (SD, 3.6 weeks; range, 27.4–39.4 weeks; median, 37.3 weeks), and the mean birth weight was 2560.9 g (SD, 771.8 g; range, 1100–3920 g; median, 2550 g). In 7 cases (31.8%), delivery was preterm. Moreover, 2 cases involved placenta accretions and 2 cases involved placenta previa. However, in none of the cases, the detected pathology was an indication for hysterectomy. There was 1 case (4.5%) of uterine rupture in the 27th week of pregnancy.

CONCLUSION

Surgery for advanced adenomyosis presents a significant technical challenge, with the need to prepare the entire surgical team. However, if such an intervention is performed correctly, significant regression or even disappearance of the disease symptoms can be expected, which is certainly associated with an improvement in the quality of life of patients.

Organ-preserving surgery for adenomyosis has limitations and is not a panacea. Such a surgery may be indicated in young patients who desire to retain their reproductive function. If adenomyomectomy is indicated, it is important to follow the surgical technique, have a surgeon experienced in performing such an intervention, and use modern surgical equipment (including surgical energies, suture material, and antispasmodic barriers). The condition of the scar or scars on the uterus can be evaluated 4–6 months after surgery prior to pregnancy planning (according to magnetic resonance imaging and ultrasound investigations). It should be kept in mind that pregnancy and delivery after adenomyomectomy often have a complicated course, with cesarean section performed for delivery. When managing pregnancy and preparing a birth plan among patients with adenomyosis who have undergone organ-preserving uterine surgery, it is necessary to take into account the data in the surgical protocol and the recommendations of the surgeon who performed the surgery.
