Single-pulse laser-induced Al transfer onto the Si wafer for ohmic contact development

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription or Fee Access

Abstract

The article examines the aluminum contacts on silicon wafers developed by the laser-induced forward transfer. It is determined that a single-pulse regime with an energy density of 15 J/cm2 leads to an aluminum concentration of 18.6% and a minimum contact resistance of 439 ± 4 Ohm. The method simplifies the contact generation process and eliminates the need for complex cleaning, making it promising for future silicon-based electronic applications.
