The new Russian system of computer-aided design and analysis of components of photonic integrated circuits of T1 Integration company (T1 IT holding) has been presented. The article analyzes the capabilities of domestic CAD, including in comparison with its foreign equivalent, which is widely used in enterprises of the Russian Federation. Special attention is paid to the applicability of the methods proposed by Russian developers.

The article continues the discussion of effects occurring in the polymer threads with the metallic fractal clusters (see Photonics Russia. 2025;19(1):14–27. DOI: 10.22184/1993-7296.FRos.2025.19.1.14.27) and considers the features of capturing external radiation with a wavelength λ in the optical wavelength range by the fractal clusters made of spherical metal particles with the radius R. An explanation is given to the effect generation conditions titled “photon localization” when the condition R << λ is met.

The article describes a homegrown embedded measuring system for the shape inspection of optical parts that can be used in the ultra-precision machines designed for diamond turning. The control system includes the contact and contactless sensors, a low-coherence interferometer, a signal converter and software that allows calculating any shape deviations of the spherical and aspherical surfaces and adjusting the CNC code to eliminate systematic shape deviations. The examples of using a contact sensor to increase the P-V shape accuracy of aspherical germanium lenses with a diameter of 90 mm from 1.4 μm to 100 nm after the systematic shape deviation compensation are provided. The possible application of a contactless sensor included in the measuring system to adjust an ultra-precision machine, as well as to control flat and cylindrical surfaces are described.

Two variants of the design of a telescopic sight with variable magnification are considered. The first one 1–10 × 24 is wide field of view 10× zoom magnification. The second one (1–4.5 × 20) is compact and lightweight 150 mm long telescopic sight. Additional attachments installed in front of objective lens and behind of eyepiece significantly expand the functionality of the telescopic sight and can easily turn it into an “smart” one.

The results of efforts on extending the dynamic range of a channel-type secondary-electron multiplier are reported. Design and process solutions are described, which allowed to achieve an increase of the output current value in linear mode. Preliminary electron scrubbing of the detector is proposed.

In order to increase plant yield and reduce radiation sources energy consumption, we introduce the concept of the cycloadaptive photomode (CAPM), which adapts to the plant development substages (steps), dynamically changes lighting parameters to optimize their growth and development, and promotes increased photosynthetic pigments synthesis. Based on the results of assessing the spectral composition of LED devices effect on the Lactuca sativa L. development, it was determined that the light-emitting device based on the automated change in the spectral composition of radiation and the photosynthetic photon flux depending density on the stage of plant development in accordance with the cycloadaptive lighting mode leads to increase Lactuca sativa L. yield by 2 times, as well as a decrease in the amount of water used to form 1 g of dry matter by 2.5 times compared to natural lighting.
