Thermal Regime of Snow Cover in Winter in The High-Mountainous Part of Elbrus According To Observational Data and Modeling Results

封面

如何引用文章

全文:

详细

Based on the analysis of the results of two measurement episodes in February 2021/22 and calculations using the LSM SPONSOR model, we obtained estimates of the variability of the snow surface thermal balance components and the thermal regime of the snowpack in the ablation zone of the Garabashi glacier on the southern slope of Mount Elbrus at 3850 m above sea level. A quantitative assessment of the sensitivity of the heat balance components to variations in key physical parameters has been performed. It is shown that the optimal value of the emissivity coefficient of snow cover in mountainous areas is 0.98: the absolute error in calculating the radiation temperature of the snow surface at this value does not exceed 1°С, in addition, the model adequately reproduces the thermal regime of deep layers of snow cover. It is also shown that a change in snow density by ±100 kg/m3 can lead to deviations in the temperature of the snow mass by several degrees. This indicates an urgent need to solve the methodological problem of measurements with thermocouples, in which the integrity of the snow mass is inevitably violated. A good agreement between the results of calculations of turbulent sensible heat fluxes in the SPONSOR model with direct measurements (correlation coefficient > 0.9) is demonstrated. Based on the measurement data, the fact of a fairly high frequency of high values of turbulent fluxes under conditions of intense radiative heating in combination with high wind speeds was revealed, which apparently turns out to be typical for high-mountain regions in winter (unlike the plains). For cases of strongly stable stratification in the surface layer, the model systematically overestimates the absolute values of heat fluxes. This may be due to the well-known problem of implementing the calculation scheme based on the Monin-Obukhov theory under conditions of temperature inversions. The inaccuracy in determining the snow surface roughness parameter, which in high mountain conditions is characterized by significant temporal variability, can contribute to the error.

作者简介

E. Drozdov

Lomonosov Moscow State University

编辑信件的主要联系方式.
Email: drozdov.jeka@yandex.ru
Russia, Moscow

D. Turkov

Institute of Geography, Russian Academy of Sciences

Email: drozdov.jeka@yandex.ru
Russia, Moscow

P. Toropov

Lomonosov Moscow State University; Institute of Geography, Russian Academy of Sciences

Email: drozdov.jeka@yandex.ru
Russia, Moscow; Russia, Moscow

A. Artamonov

A.M. Obukhov Institute of Atmospheric Physics, Russian Academy of Sciences

Email: drozdov.jeka@yandex.ru
Russia, Moscow

参考

  1. Voloshina A.P. Meteorology of mountain glaciers. Materialy Glyatsiologicheskikh Issledovaniy. Data of Glaciological Studies. 2001, 92: 3–148 p. [In Russian].
  2. Gandin L.S., Kagan R.L. Statisticheskie metody interpretatsii meteorologicheskich dannyh. Statistical methods for interpreting meteorological data. Leningrad: Hydrometeoizdat, 1976: 360 p. [In Russian].
  3. Gusev E.M., Nasonova O.N., Dzogan L.Ya., Ayzel G.V. Modeling the formation of river runoff and snow cover in the north of the largest Siberia. Vodnye Resursy. Water Resources. 2015, 42 (4): 387–395. [In Russian].
  4. Drozdov E.D., Toropov P.A., Turkov D.V., Shestakova A.A., Androsova E.E. Estimation of the effect of sublimation of ice crystals during snowstorms over the surface of a mountain glacier based on field data and numerical simulation. Sovremennye tendentsii i perspektivy razvitiya gidrometeorologii v Rossii: Materialy IV Vserossiyskoy nauchno-prakticheskoy konferentsii, priurochennoy k Godu nauki I technologiy. Modern trends and prospects for the development of hydrometeorology in Russia: Proceedings of the IV All-Russian Scientific and Practical Conference dedicated to the Year of Science and Technology. Irkutsk: Irkutsk State University Publishing House, 2021: 397–404. [In Russian].
  5. Dyunin A.K. Mekhanika meteley. Blizzard mechanics. Novosibirsk: Siberian Branch of the Academy of Sciences of the USSR, 1963: 378 p. [In Russian].
  6. Russia glacier inventory. Retrieved from: https://www.glacrus.ru (Last access: 04.06.2022). [In Russian].
  7. Ledniki i klimat Elbrusa. Glaciers and climate of Elbrus. Мoscow, Saint Petersburg: Nestor–Istoria, 2020: 372 p. [In Russian].
  8. Oledenenie Elbrusa. Elbrus glaciation. Moscow: Moscow University Press, 1968: 345p. [In Russian].
  9. Osokin N.I., Sosnovskiy A.V., Chernov R.A. Thermal conductivity of snow and its variability. Kriosfera Zemli. Cryosphere of the Earth. 2017, XXI (3): 60–68. https://doi.org/10.21782/KZ1560-7496-2017-3(60-68). [In Russian].
  10. Pavlov A.V. Teplofizika landschaftov. Thermal physics of landscapes. Novosibirsk: Nauka, 1979: 286 p. [In Russian].
  11. Repina I.A., Stepanenko V.M., Barskov K.V., Pashkin A.D., Artamonov A.Yu. Interaction of the atmosphere with an inhomogeneous underlying surface. Dinamika i vzaimodeystvie geosfer zemli: materialy Vserossiyskoy konfe-rentsii s mezhdunarodnym uchastiem, posvyashennoy 100-letiyu podgotovki v Tomskom gosudarstvennom universitete spezialistov v oblasti nauk o zemle. Dynamics and interaction of the earth’s geospheres: Proceedings of the All-Russian conference with international participation dedicated to the 100 th anniversary of the training of specialists in the field of earth sciences at Tomsk State University. Tomsk: TGU, 2021: 187–190. [In Russian].
  12. Toropov P.A., Michalenko V.N., Kutuzov S.S., Morozova P.A., Shestakova A.A. Temperature and radiation regime of glaciers on the slopes of Elbrus during the ablation period over the past 65 years. Led i Sneg. Ice and Snow. 2016, 56 (1): 5–19 [In Russian]. https://doi.org/10.15356/2076-6734-2016-1-5-19
  13. Toropov P.A., Shestakova A.A., Smirnov A.M., Popovnin V.V. Assessment of the components of the heat balance of the Dzhankuat glacier (Central Caucasus) during the ablation period in 2007–2015. Kriosfera Zemli. Cryosphere of the Earth. 2018, XXII (4): 42–54 [In Russian]. https://doi.org/10.21782/KZ1560-7496-2018-4(42-54)
  14. Turkov D.V., Sokratov V.S. Calculation of snow cover characteristics of flat areas using the SPONSOR local heat and moisture exchange model and reanalysis data on the example of the Moscow region. Led i Sneg. Ice and Snow. 2016, 56 (3): 369–380 [In Russian]. https://doi.org/10.15356/2076-6734-2016-3-369-380
  15. Shmakin A.B., Rubinshtein K.G. Validation of the dynamic-statistical method for detailing meteorological parameters. Trudy Gidrometcentra Rossii. Proc. of the Hydrometeorological Center of Russia. 2006, 341: 186–208. [In Russian].
  16. Shmakin A.B., Turkov D.V., Michailov A.Yu. Snow cover model taking into account the layered structure and its seasonal evolution. Kriosfera Zemli. Cryosphere of the Earth. 2009, XIII (4): 69–79. [In Russian].
  17. Bintanja R., Van Den Broeke M.R. The Surface Energy Balance of Antarctic Snow and Blue Ice. Journ. of Applied Meteorology. 1995, 34: P. 902–926. https://doi.org/10.1175/1520-0450(1995)034<0902:TSEBOA>2.0.CO;2
  18. Boone A., Etchevers P. An Intercomparison of Three Snow Schemes of Varying Complexity Coupled to the Same Land Surface Model: Local-Scale Evaluation at an Alpine Site. Bull. Amer. Meteorol Society. 2001, 2 (4): 374–394. https://doi.org/10.1175/1525-7541(2001)0022.0.CO;2
  19. Essery R., Semenov V., Turkov D. Snow cover duration trends observed at sites and predicted by multiple models. The Cryosphere. 2020, 14: 4687–4698. https://doi.org/10.5194/tc-14-4687-2020
  20. Etchevers P., Martin E., Brown R. Validation of the energy budget of an alpine snowpack simulated by several snow models (SnowMIP project). Annals of Glaciology. 2004, 38: 150–158. https://doi.org/10.3189/172756404781814825
  21. High Mountain Areas in IPCC Special Report on the Ocean and Cryosphere in a Changing Climate (The Intergovernmental Panel on Climate Change (IPCC), 2019). Lead authors R. Hock, G. Rasul, S. Kutuzov et al. 2019.
  22. Kominami Y., Endo Y., Niwano Sh., Ushioda S. Viscous compression model for estimating the depth of new snow. Annals of Glaciology. 1998, 26: 77–82.
  23. Krinner G., Derksen C., Richard E. et al. ESM-SnowMIP: assessing snow models and quantifying snow-related climate feedbacks. Geosci. Model Dev. 2018, 11: 5027–5049. https://doi.org/10.5194/gmd-11-5027-2018
  24. Menard C., Essery R., Turkov D. Scientific and human errors in a snow model intercomparison. Bull. Amer. Meteorol Society. 2021, 2021 (1): E61–E79. https://doi.org/10.1175/BAMS-D-19-0329
  25. Landry C.C., Buck K.A., Raleigh M.S., Clark M.P. Mountain system monitoring at Senator Beck Basin, San Juan Mountains, Colorado: A new integrative data source to develop and evaluate models of snow and hydrologic processes. Water Resour. Res. 2014, 50: 1773–1788. https://doi.org/10.1002/2013WR013711
  26. Lapo K., Nijssen B., Lundquist J.D. Evaluation of Turbulence Stability Schemes of Land Models for Stable Conditions. Journ. of Geophys. Research: Atmosphere. 2019, 124 (6): 3072–3089. https://doi.org/10.1029/2018jd028970
  27. Lejeune Y., Dumont M., Panel J.-M., Lafaysse M., Lapalus P., Le Gae E., Lesaffre B., Morin S. 57 years (1960–2017) of snow and meteorological observations from a mid-altitude mountain site (Col de Porte, France, 1325m of altitude). Earth Syst. Sci. Data. 2019, 11: 71–88. https://doi.org/10.5194/essd-11-71-2019
  28. Liu S., Lu L., Mao D., Jia L. Evaluating parameterizations of aerodynamic resistance to heat transfer using field measurements. Hydrology and Earth System Sciences. 2007, 2 (11): 769–783. https://doi.org/10.5194/hess-11-769-2007
  29. Marzeion B., Jarosch A.H., Gregory J.M. Feedbacks and mechanisms affecting the global sensitivity of glaciers to climate change. The Cryosphere. 2014, 8: 59–71.
  30. Pomeroy J.W., Jones H.G. Wind-Blown Snow: Sublimation, transport and changes to polar snow, in: Chemical exchange between atmosphere and polar snow. In: NATO ASI Series, edited by: Wolff, E. and Bales, R.C., Springer-Verlag, Berlin, Heidelberg. 1996, 43: 453–489.
  31. Slater A.G., Schlosser C.A., Desborough C.E. The representation of snow in land surface schemes: results from PILPS 2(d) // Journ. of Hydrometeorology. 2001, 2 (1): 7–25.
  32. Shmakin A.B. The updated version of SPONSOR land surface scheme: PILPS-influenced improvements. Global and Planetary Change. 1998, 19 (1–4): P. 49–62.
  33. Snow and Climate. Ed. by R.L. Armstrong, E. Brun. Cambridge, U.K. Cambridge Univ. Press, 2008: 222 p.
  34. Sokratov S.A., Sato A. The effect of wind on the snow cover. Annals of Glaciology. 2001, 32: 116–120.
  35. Sturm M., Holmgren J., Konig M., Morris K. The thermal conductivity of seasonal snow. Journal of Glaciology. 1997, 43 (143): 26–41.
  36. Toropov P.A., Aleshina M.A., Grachev A.M. Large-scale climatic factors driving glacier recession in the Greater Caucasus, 20th–21st century. Intern. Journ. of Climatology. 2019: 4703–4720. https://doi.org/10.1002/joc.6101
