Сhevkinite-(Се) and perrierite-(Се) in the island arc quartz gabbro-norite-dolerites of the Ayu-Dag intrusion, Rocky Crimea

封面

如何引用文章

全文:

开放存取 开放存取
受限制的访问 ##reader.subscriptionAccessGranted##
受限制的访问 订阅或者付费存取

详细

Сhevkinite-(Се) and perrierite-(Се) are minerals characteristic for alkaline magmatic rocks and high-temperature alkaline metasomatites, and yet they are typical accessory minerals in Mesozoic island-arc gabbroids of the Rocky Crimea. Early magmatic mineral associations in these low-alkaline rocks of Ayu-Dag intrusion include accessory Ti—Zr—LREE minerals under-saturated in silica: chevkinite-(Се), perrierite-(Се), zirconolite, baddeleyite. Сhevkinite and perrierite occur as isolated shortly prismatic crystals up to 0.1 mm in size and strongly corroded inclusions in center of late-magmatic allanite-(Ce) crystals. Both minerals are the main concentrators of lanthanides in Aju-Dag gabbroids. Distribution of lanthanides in them is as following: Ce ˃> La > > Nd >> Pr > Gd, Sm, Tb, Dy. Contents of lanthanides in chevkinite and perrierite are identical: Ce (54—58 % REE) — La (25—31 %) — Nd (12—20 %). Contents of Zr, Th, Y, Sc in both polymorphs are identical also. Сhevkinite-(Ce) of isolated crystals is magnesium-dominant; its composition is: [Cе1.5La0.8—0.9Nd0.3—0.4Pr0.1(Gd+Sm+Tb+Dy)0.1Y0.2Sc0.1Ca0.7—0.8Na0.1]4(Mg0.5Fe3+0.5)1 × (Fe3+1.1—1.2Ti0.4—0.7Zr0.1—0.2Al0.1—0.2)2Ti2[(Si3.7—4Al0.3—0)4O22]. Сhevkinite-(Ce) from inclusions in allanite is poor in Mg, its formula is: [Cе1.5—1.7La0.6—0.9Nd0.5—0.6Pr0.1(Gd+Sm)0.1Y0.1—0.2Sc0.1Ca0.6—0.8Na0.1]4 × (Fe2+0.6—1Mg0—0.1Fe3+0—0.4)1(Ti0.8—0.9Fe3+0.3—0.7Al0.2—0.4Zr0—0.2)2Ti2[(Si3.9—4Al0.1—0)4O22]. Perrierite-(Ce) composing idiomorphic crystals is magnesium-dominant, its composition is: [Cе1.2—1.6La0.6—0.8Nd0.3—0.4Pr0.1 × (Gd+Sm+Tb+Dy)0.1Y0.1Sc0.1Ca1.0—1.1Sr0—0.1Na0.1]4(Mg0.9—1Fe3+0.1—0)1(Fe3+1.0—1.2Al0.2—0.7Ti0.3—0.5Zr0—0.2)2Ti2 × [(Si3.9—4Al0.1—0)4(O21.3—21.5OH0.7—0.5)22]. Perrierite-(Ce) occurring inside allanite is poor in Mg, with the formula: [Cе1.3—1.5La0.7—0.8Nd0.3—0.5Pr0.1(Gd+Sm)0.1Y0.1Sc0.1Ca1.1—1.3Na0.1]4(Fe2+0.4—0.5Fe3+0.2—0.4Mg0.2)1 × (Al0.5—0.7Ti0.3—0.8Fe3+0.3—0.9Zr0.1—0.3)2Ti2[(Si3.9—4Al0.1—0)4(O21.4—22OH0.6—0)22]. Presence of chevkinite, perrierite and zirconolite in unusual geochemical settings may be explained perhaps by poor development of late-magmatic processes in near-surface intrusions of Crimeaʼs Mesozoids.

Perhaps, the presence of chevkinite and perrierite, as well as zirconolite in unusual geochemical settings can be explained by poor development of late-magmatic processes in near-surface intrusives of the Mountain Crimea mesozoids.

全文:

受限制的访问

作者简介

Ernst Spiridonov

Lomonosov Moscow State University

Email: ernstspiridon@gmail.com
SPIN 代码: 2534-3064

Professor, Dr. geol.-min. sciences, Professor, Department of Mineralogy, Geological Faculty



俄罗斯联邦, 119234, Russia, Moscow, Lenin Hills, 1

Sergey Filimonov

Lomonosov Moscow State University

Email: sefi@geol.msu.ru
SPIN 代码: 1446-7970

Candidate geol.-min. Sci., Associate Professor, Department of Mineralogy, Geological Faculty

Moscow, Lenin Hills, 1 Russia

Evgenia Semikolennyh

A.P. Karpinsky Russian Geological Research Institute

Email: geny_shen@mail.ru

Researcher

199106, St. Petersburg, Sredny ave., 74

Natalia Korotaeva

Lomonosov Moscow State University

Email: mineral@geol.msu.ru

Leading Engineer of the Laboratory for Local Research Methods at the Department of Petrology, Geological Faculty

Moscow, Lenin Hills, 1 Russia

Nadezhda Krivitskay

Lomonosov Moscow State University

编辑信件的主要联系方式.
Email: nnkriv@mail.ru
SPIN 代码: 8010-0291

Senior Researcher Candidate geol.-min. Sciences, Senior Researcher, Department of Mineralogy, Geological Faculty
grant

Moscow, Lenin Hills, 1 Russia

参考

  1. Ananiev V. A., Reverdatto V. V. Unic association Fe-apatite-Fe-cordierite-fayalite of the Au-Dag - product at contact metamorphism. Doklady Earth Sci. 1997. Vol. 353. N 3. P. 362-364 (in Russian).
  2. Barsanov G. P. Minerals at Ilmeny nature reserve. Ural. branch USSR Acad. Sci., 1949. 475 p.
  3. Belkin H. E., Macdonald R., Grew E. S. Chevkinite-group minerals from granulite-facies metamorphic rocks and associsated pegmatites of East Antarctica and South India. Miner. Mag. 2009. Vol. 73. P. 149-164.
  4. Boldyrev A. K., Betechtin A. G., Godlevsky M. N., Grigoriev D. P., Kisilev A. I., Levitsky O. D., Razumovsky N. K., Smirnov A. A., Sobolev V. S., Coloviev S. P., Uspensky N. M., Chernych V. V., Chatalov E. T., Shafranovsky I. I. Mineralogy. Moscow; Leningrad: ONTI, 1938. 1136 p. (in Russian).
  5. Bonatti S. Chevkinite, perrierite and epidotes. Amer. Miner. 1959. Vol. 44. P. 115-137.
  6. Bonatti S., Gottardi G. Nuovi dati sulla perrierite. R. C. Soc. Mineral. Ital. 1954. Vol. 10. P. 208-225.
  7. Carlier G., Lorand J.-P. Zr-rich accessory minerals (titanite, perrierite, zirconolite, baddeleyite) record strong oxidation associated with magma mixing in the South Peruvian potassic province. Lithos. 2008. Vol. 104. P. 54-70.
  8. Cryzanovsky V. I. Chevkinite from Ilmeny mountains. Proc. Russ. Acad. Sci. VI ser. 1924. Vol. 18. N. 12-18. P. 321-326 (in Russian).
  9. Eremenko G. K., Eremenko E. I. Calc-silicate hornfels at Au-Dag. Dokl. Acad. Sci. Ukr. SSR. Ser. B. 1972. N 7. P. 585-589 (in Russian).
  10. Ganseev A. A., Grechischev O. K. New genetic type of the rare metals alcaly granites at Madagascar. Russian Geol. Geophys. 2003. Vol. 44. N 6. P. 539-553 (in Russian).
  11. Geochemistry, moneralogy and genetic types of the rare elements deposits (ed. K. A. Vlasov). Vol. 2. Moscow: Nauka, 1964. 830 p. (in Russian).
  12. Haggerty S. E., Mariano A. N. Strontian loparite and strontiochevkinite: Two new minerals in rheomorphic fenites from the Paranfi Basin carbonatites, South America. Contrib. Mineral. Petrol. 1983. Vol. 84. P. 365-381.
  13. Halleran A. A. D., Russell J. K. REE-bearing alkaline pegmatites and associated light REE-enriched fenites at Mount Bisson, British Columbia. Econ. Geol. 1996. Vol. 91. P. 451-459.
  14. Heinrich E. W. Mineralogy and geology of radioactive raw materials. New-York: MacGraw-Hill, 1958. 614 p.
  15. Ito J., Arem J. E. Chevkinite and perrierite: synthesis, crystal growth and polymorphism. Amer. Mineral. 1971. Vol. 56. P. 307-319.
  16. Izett G. A., Wilcox R. E. Perrierite, chevkinite, and allanite in upper Cenozoic ash beds in the western United States. Amer. Miner. 1968. Vol. 53. P. 1558-1567.
  17. Jaffe H. W., Evans H. T., Chapman R. W. Occurrence and age of chevkinite from the Devilʼs Slide fayalite-quartz syenite near Stark, New Hampshire. Amer. Miner. 1956. Vol. 41. P. 474- 487.
  18. Kapustin Yu. L. Chevkinite from fenites in alcaly intrusions of the Eastern Tuva. Proc. Miner. Museum RAS. 1987. Vol. 34. P. 71-75 (in Russian).
  19. Kaufman A., Jaffe H. Chevkinite from Arizona. Amer. Miner. 1946. Vol. 31. P. 582-588.
  20. Lacroix A. La tscheffkinite de Madagascar. Bull. Soc. Fran. Minér. 1915. Vol. XXXVIII. P. 106.
  21. Lagorio A. E. About geology at Crimea. Proc. Warsaw. Univ. 1887. N 5. P. 1-16. N 6. P. 17-48.
  22. Larsen A. O., Andersen F., Berge S. A., Burvald I., Dahlgren S., Larsen K. E. The Langesundsfjord. History, geology, pegmatites, minerals. Bode Verlag GmbH: Salzhemendorf, Germany. 2010. 279 s.
  23. Lazarenko E. K., Lavrinenko LFФ., Bachinskaya N. I. Mineralogy of the Priazovie. Kiev: Naukova Dumka, 1981. 431 p. (in Russian).
  24. Luchitsky V. I. Petrography of Crimea. Petrography Soviet Union. Ser. 1. Regional petrography. N 8. Moscow; Leningrad: USSR Acad. Sci., 1939. 98 p. (in Russian).
  25. Lyachovich V. V. Accessory minerals in granitouds of Soviet Union. Moscow: Nauka, 1967. 447 p. (in Russian).
  26. Macdonald R., Bagin´ski B., Dzierz˙anowski P., Fettes D. J., Upton B. G. J. Chevkinite-group minerals in UK Palaeogene granites: Underestimated REE-bearing accessory phases. Canad. Miner. 2013. Vol. 51. Р. 333-347.
  27. Macdonald R., Bagin´ski B., Kartashov P., Zozulya D., Dzierz˙anowski P. Chevkinite-group minerals from Russia and Mongolia: new compositional data from metasomatites and ore deposits. Miner. Mag. 2012. Vol. 76. Р. 535-549.
  28. Macdonald R., Belkin H. E. Compositional variation in minerals of the chevkinite group. Miner. Mag. 2002. Vol. 66. P. 1075-1098.
  29. Macdonald R., Marshall A. S., Dawson J. B., Hinton R. W., Hill P. G. Chevkinite-group minerals from salic volcanic rocks of the East African Rift. Mineral. Mag. 2002. Vol. 66. Р. 287-299.
  30. Marshall A. S., Hinton R. W., Macdonald R. Phenocrystic fluorite in peralkaline rhyolites, Olkaria, Kenya Rift Valley. Miner. Mag. 1998. Vol. 62. P. 477-486.
  31. McDowell S. D. Chevkinite from the Little Chief granite porphyry stock, California. Amer. Miner. 1979. Vol. 64. P. 721-727.
  32. Meister А. K. Materials at petrography of the Crimea. Izvestija Geolkoma. 1908. Vol. 27. N 10. P. 669-706 (in Russian).
  33. Mills S. J., Kartashov P. M., Kampf A. R., Konev A. A., Koneva A. A., Raudsepp M. Cordylite-(La), a new mineral species in fenite from the Biraya Fe-Ree deposit, Irkutsk, Russia. Canad. Miner. 2012. Vol. 50. P. 1281-1290.
  34. Morozova E. B., Sergeev S. A., Sufiev A. A. U-Pb zircon (Shrimp) age of the Djidair intrusion as reference subject for geology at Crimea. Vestnik SPbSU. Ser. 7. Geol. Geogr. 2012. N 4. P. 25-33 (in Russian).
  35. Muhling J. R., Suvorova A. A., Birger R. The occurrence and composition of chevkinite-(Ce) and perrierite-(Ce) in tholeiitic intrusive rocks and lunar mare basalt. Amer. Miner. 2014. Vol. 99. P. 1911-1921.
  36. Murata K. L., Rose H. I., Carron M. K., Glass J. J. Systemathic variations of rare earth elements in cerium-rich minerals. Geochim. Cosmochim. Acta. 1957. Vol. 11. P. 141-161.
  37. Muratov M. V. Geology of Crimea peninsula. Moscow: Nedra, 1973. 192 p. (in Russian).
  38. Papoutsa A. D., Pe-Piper G. The relationship between REE-Y-Nb-Th minerals and the evolution of an A-type granite, Wentworth Pluton, Nova Scotia. Amer. Miner. 2013. Vol. 98. P. 444-462.
  39. Ploshko V. V., Sidenko O. G., Ivanov V. I., Sukach V. S. Association of the picrites and quartz diabazes of Crimea. Doklady USSR Acad. Sci. 1979. Vol. 244. P. 442-445 (in Russian).
  40. Popov S. P. Minaralogy of Crimea. Moscow: USSR Acad. Sci., 1938. 352 p. (in Russian).
  41. Reed S. J. B. Electron microprobe and scaning electron microscopy at geology. Cambridge: University Press, 2005. 190 p.
  42. Ridolfi F., Renzulli A., Santi P., Upton B. G. J. Evolutionary stages of crystallization of weakly peralkaline syenites: evidence from ejecta in the plinian deposits of Agua de Pau volcano (São Miguel, Azores Islands). Miner. Mag. 2003. Vol. 67. P. 749-767.
  43. Savelieva V. B., Karmanov N. S. Rare earths’ minerals of alkaline metasomatites in the Main Sayan Fault zone. Zapiski RMO (Proc. Russian Miner. Soc.). 2008. Vol. 137. N 2. P. 31-52 (in Russian).
  44. Scaillet B., Macdonald R. Phase relations of peralkaline silicic magmas and petrogenetic implications. J. Petrol. 2001. Vol. 42. Р. 825-845.
  45. Segalstad T. V., Larsen A. O. Chevkinite and perrierite from the Oslo region, Norway. Amer. Miner. 1978. Vol. 63. P. 499-505.
  46. Sokolova E., Hawthorne F. C., Ventura G. della, Kartashov P. M. Chevkinite-(Ce): crystal structure and the effect of moderate radiation-induced damage on site-occupancy refinement. Canad. Miner. 2004. Vol. 42. P. 1013-1025.
  47. Sørensen H. The agpaitic rocks: an overview. Miner. Mag. 1997. Vol. 61. P. 485-498.
  48. Spiridonov E. M., Fedorov T. O., Ryachovsky V. M. Magmatism of Rocky Crimea. Article 1 and 2. Bull. MOIP. Geology. 1990. Vol. 65. N. 4. P. 119-134, N 6. P. 102-112 (in Russian).
  49. Spiridonov E. M., Filimonov S. V., Korotaeva N. N., Semikolennych E. S. Zirconolite, baddeleite, chevkinite, ilmenite, zircon, thorite, allanite, monazite of the island arc quartz anorthite - bytownite gabbro-norite-dolerites within the Aju-Dag intrusion, Rocky Crimea. Fedorov session 2016. Saint Petersburg: LEMA, 2016. P. 171-173 (in Russian).
  50. Spiridonov E. M., Filimonov S. V., Semikolennych E. S., Korotaeva N. N., Krivitskaya N. N. Zirconolite, baddeleite, zircon and thorite of the island arc quartz gabbro-norite-dolerites within the Aju-Dag intrusion, Rocky Crimea. Moscow University Geol. Bull. 2018. N 6. P. 538-548.
  51. Troll V. R., Sachs P. M., Schmincke H.-U., Sumita M. The REE-Ti mineral chevkinite in comenditic magmas from Gran Canaria, Spain: a SYXRF-probe study. Contrib. Mineral. Petrol. 2003. Vol. 145. P. 730-741.
  52. Vlach S., Gualda G. Allanite and chevkinite in A-type granites and syenites of the Graciosa Province, southern Brazil. Lithos. 2007. Vol. 97. Р. 98-121.
  53. Young E. J., Powers H. A. Chevkinite in volcanic ash. Amer. Miner. 1960. Vol. 45. P. 875-881.
  54. Zazicha B. V. Postmagmatic mineralization from granitoids of the Kamennych Mogil (Priazovie). In: Ore-forming environment on the inclusions in minerals. Moscow: Nauka, 1972. P. 178-184 (in Russian).
