Platinum-bearing of chromitites from the Kurtushibinsky ofiolite belt, Western Sayan: new data

封面

如何引用文章

全文:

开放存取 开放存取
受限制的访问 ##reader.subscriptionAccessGranted##
受限制的访问 订阅或者付费存取

详细

Small scattered grains of PGE minerals have been found in chromitites of Ergaksky and Kalninsky ultramafic massifs, which are extreme northeastern fragments of the Kurtushibinsky Ophiolite Belt of Western Sayan. For the first time, together with previously known PGE minerals, there were found the Cu—Ru—Os solid solution, arsenic-bearing (As up to 3.6 wt %) laurite with minor Pt, Ni, and Co, PGE sulfides of MeS and Me3S4 types, sulfoarsenide with the high content of Rh (~12.7 wt %) in chromitites of the Ergaksky massif, and laurite and sulfoarsenides in chromitites of the Kalninsky massif. Compositions of PGE minerals indicate high temperature of the Ru—Os sulfide formation (~1200—1250 ºC) in both massifs, as well as high partial pressure of sulfur under the formation of chromitites and syngenetic PGE minerals in the Ergaksky massif. PGE mineral assemblages were formed in several stages. Os—Ir—Ru solid solutions and disulfides of the laurite—erlichmanite series (mainly fractionating ruthenium) formed earlier than Cu—Ru—Os solid solutions, sulfides (Ru,Fe)3S4, (Ru,Ni,Fe)S, and PGE sulfoarsenides, which crystallized under influence of reduced fluids as a result of remobilization and redeposition of PGE.

全文:

受限制的访问

作者简介

Alexey Yurichev

Tomsk State University

编辑信件的主要联系方式.
Email: juratur@sibmail.com

candidate of geological and mineralogical sciences, associate professor of department of petrography, Senior Researcher of laboratory of geochronology and geodynamics

俄罗斯联邦, 634050, Russia, Tomsk, Lenin Avenue, 36

Alexey Chernyshov

Tomsk State University

Email: aich@ggf.tsu.ru

doctor of geological and mineralogical sciences, professor, head of department of petrography

俄罗斯联邦, 634050, Russia, Tomsk, Lenin Avenue, 36

参考

  1. Ahmed A. H., Arai S. Platinum-group minerals in podiform chromitites of the Oman ophiolite. Canad. Miner. 2003. Vol. 41. P. 597-616.
  2. Andrews D. R. A., Brenan J. M. Phase-equilibrium constraints on the magmatic origin of laurite and Os-Ir alloy. Canad. Miner. 2002. Vol. 40. P. 1705-1716.
  3. Chernyshov A. I., Yurichev A. N. Petrostructural evolution of ultramafic rocks of the Kalninsky chromite-bearing massif, Western Sayan. Geotectonics. 2013. Vol. 47. No. 4. С. 266-278 (in Russian).
  4. Chernyshov A. I., Kicheeva A. V., Podlipsky M. Yu. Petrostructural heterogeneities of ultramafites of the Ergaksky chromite-bearing massif (West Sayan). Zapiski RMO (Proc. Russian Miner. Soc). 2016. Vol. 145. No. 5. P. 25-38 (in Russian).
  5. Chernyshov A. I., Loskutov I. Yu., Kicheeva A. V., Podlipsky M. Yu. Chromite potential of ultramafites from Ergaksky massif, northeast of the Western Sayan. Ores and metals. 2018. No. 1. C. 47-53 (in Russian).
  6. Distler V. V., Kryachko V. V., Yudovskaya M. A. Formation conditions of platinum-group metals in chromite ores of the Kempirsai ore field. Geol. Ore Deposits. 2003. Vol. 45. No. 1. P. 37-65.
  7. Dodin D. A., Landa E. A., Lazarenkov V. G. Platinum metal deposits of the world. Vol. 2. Platinum-containing chromite and titanomagnetite deposits. Moscow: Geoinformtsentr LLC, 2003. 409 p. (in Russian).
  8. Garuti G., Zaccarini F. In situ alteration of platinum-group minerals at low temperature: evidence from serpentinized and weathered chromitites of the Vourinos Complex, Greece. Canad. Miner. 1997. Vol. 35. P. 611-626.
  9. Garuti G., Pushkarev E. V., Zaccarini F. Compositions and paragenesis of Pt alloys from chromitites of the Ural-Alaskan type Kytlym and Uktus complexes, Northern and Central Urals, Russia. Canad. Miner. 2002. Vol. 40. P. 357-376.
  10. Gurskaya L. I., Smelova L. V., Kolbantsev L. R., Lyakhnitskaya V. D., Lyakhnitsky Yu. S., Shakhova S. N. Platinoids of chromite-bearing massifs of the Polar Urals. Saint Petersburg: VSEGEI, 2004. 306 p. (in Russian).
  11. Kiseleva O. N., Zhmodik S. M., Agafonov L. V., Belyanin D. K., Damdinov B. B. Composition and evolution of PGE mineralization in chromite ores from the Il’chir ophiolite complex (Ospa-Kitoi and Kharanur areas, East Sayan). Russian Geol. Geophys. 2014. Vol. 55. No. 2. P. 259-272.
  12. Krivenko A. P., Podlipsky M. Yu., Kubyshev A. I., Katanov S. G. Prospects of chromite-bearing and platinum-bearing of hyperbasites of Upper-Amyl region in the Western Sayan. In: Mineral resources of Krasnoyarsk Region. Krasnoyarsk: Krasnoyarsk Res. Inst. Geol. Miner. Res., 2002. P. 314-324 (in Russian).
  13. Krivenko A. P., Podlipsky M. Yu., Agafonov L. V. Ore mineralization of hyperbasites of Ergaksky massif and prospects for its chromite-bearing. In: Condition and development of natural resources of Tuva and adjacent regions of Central Asia. Geoecology of natural environment and society. Issue 8. Kyzyl: Tuvinian Inst. Explor. Natural Res. Siberian Branch RAS, 2005. P. 32-44 (in Russian).
  14. Legendre O., Augе T. Mineralogy of platinum-group mineral inclusions in chromites from different ophiolitic complexes. In: Metallogeny of Basic and Ultrabasic Rocks. London: Inst. Mining and Metallurgy, 1986. P. 361-372.
  15. Loskutov I. Yu., Chernyshov A. I., Kicheeva A. V. Communication of chemistry and ore-bearing of hyperbasites of Kalninsky massif (Western Sayan). Tomsk State University Bull. 2015. No. 400. P. 366-370 (in Russian).
  16. Malich K. N., Badanina I. Yu., Knauf V. V., Meisel T. Mineralogical-geochemical associations of platinoids of dunite-garzburgite and clinopyroxenite-dunite massifs. Proc. Inst. Geol. Geochem. Ural Branch RAS. 2013. Vol. 160. P. 255-260 (in Russian).
  17. Melcher F., Grum W., Simon G., Thalhammer T. V., Stumpfl E. F. Petrogenesis of the ophiolitic giant chromite deposits of Kempirsai, Kazakhstan: a study of solid and fluid inclusions in chromite. J. Petrol. 1997. Vol. 38. P. 1419-1458.
  18. Osipenko A. B., Sidorov E. G., Kostojanov A. I., Tolstykh N. D. Chromitites of ultramafic complexes of the Valizhgen Peninsula, Koryak Highland. Geol. Ore Deposits. 2002. Vol. 44. No. 1. P. 69-83.
  19. Petrology and metamorphism of ancient ophiolites (by example of the Polar Urals and the Western Sayan). V.S. Sobolev and N.L. Dobretsov (eds). Novosibirsk: Nauka, 1977. 222 p. (in Russian).
  20. Podlipsky M. Yu., Krivenko A. P. Platinum-chromite mineralization in ophiolite hyperbasites of the Western Sayan. In: Platinum of Russia. New unconventional types of deposits and ore occurrences of platinum-containing raw materials. 2005. Vol. 6. P. 100-109 (in Russian)
  21. Pushkarev E. V., Anikina E. V., Garuti J., Zakkarini F. Chromium-platinum deposits of nizhny-tagil type in the Urals: structural-substantial characteristic and а problem of genesis. Lithosfera. 2007. No. 3. P. 28-65 (in Russian).
  22. Sidorov E. G., Kozlov A. P., Tolstykh N. D. Galmoehnan basite-hyperbasite massif and its platinum content. Moscow: Scientific world, 2012. 288 p. (in Russian).
  23. Talhammer T. V. Association of minerals of platinum group in massive chromite ores of Kempirsai ophiolite complex (Southern Urals) as manifestation of mantle metasomatism. Zapiski RMO (Proc. Russian Miner. Soc.). 1996. No. 1. P. 25-36 (in Russian).
  24. Volkova N. I., Stupakov S. I., Rudnev S. N., Babin G. A., Mongush A. A. Mobility of trace elements during subduction metamorphism as exemplified by the blueschists of the Kurtushibinsky range, Western Sayan. Geochem. Int. 2009. Vol. 47. No. 4. P. 380-392.
  25. Yekhanin D. A. Geological structure and ore potential of Kalninsky ultrabasic massif. Prospect Protect. Miner. Res. 2010. No. 9. P. 24-28 (in Russian).
  26. Yurichev A. N. Kalninsky ultramafic massif of the Western Sayan: ore mineralization and its genetic nature. Bull. Tomsk Polytech. University. 2015. Vol. 326. No. 2. P. 61-69 (in Russian).
  27. Zabiyaka A. I. Upper-Amyl chromite-bearing region. In: Geology and minerals of Krasnoyarsk region. Issue 9. Krasnoyarsk: Krasnoyarsk Res. Instit. Geol. Miner. Res., 2008. P. 193-205 (in Russian).
  28. Zaccarini F., Pushkarev E., Garuti G. Platinum-group element mineralogy and geochemistry of chromitite of the Kluchevskoy ophiolite complex, central Urals (Russia). Ore Geol. Rev. 2008. Vol. 33. P. 20-30.
  29. Zhou M-F., Robinson P., Malpas J., Li Z. Podiform chromites in the Luobusa Ophiolite (Southern Tibet): implications for melt-rock interaction and chromite segregation in the upper mantle. J. Petrol. 1996. Vol. 37. P. 3-21.
