Morphofunctional remodeling of bone tissue during periprotheric fractures in the femoral component

Cover Page
Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription or Fee Access

Abstract


Periprosthetic fractures in the area of the femoral component after hip replacement are one of the reasons for performing revision surgery. The treatment is always associated with many complications and therefore does not lose its relevance. The aim of our research was a pathomorphological study of bone tissue repair and reactive changes in the soft tissues around the periprosthetic fracture after arthroplasty. The research results will predict the long-term outcome and stability of the revision endoprosthesis.

Materials and methods. The materials for pathomorphological studies were biopsy, (11 — periprosthetic fractures in the zone of the femoral component, 5 — from the hip joint), fragments of bone tissue from the zone of the periprosthetic fracture, femoral canal, altered connective tissue obtained by repeated interventions in the area of periprosthetic fracture, and revision endoprosthetics. Pathomorphological studies of biopsy specimens of bone fragments and soft tissues were carried out after conventional histological processing with the production of histological sections, 5–7 μm thick, followed by staining with hematoxylin and eosin and according to Van Gieson.

Results. Morphological signs of structural disorganization of bone tissue in the fracture zone were revealed after fragments of bone and soft tissues were removed from the fracture zone; various options for repair of bone tissue were investigated, as well as reactive changes up to ischemia from the surrounding soft tissues were observed. Signs of damage to the tubules, lacunae and trabeculae, and with them the intraosseous branches of the supplying artery were noticed. Bone tissue repair in the area of periprosthetic fractures was carried out in various ways: due to activation of osteoblasts, through endesmal osteogenesis (from preexisting fibrous structures), endochondral osteogenesis (from provisional corns), as well as mixed osteogenesis from complexes of bone–cartilaginous tissue. Slowing of osteogenesis was the reason for the formation of appositional gluing lines in bone trabeculae, which are considered as a morphological sign of delayed osteogenesis. The absence of multinucleated osteoclasts in the bone tissues we studied is apparently due to the fact that pathological osteolysis with signs of ischemia does not develop in the fracture zone.

Conclusion. The results of our histopathological studies indicate that by the time of revision endoprosthetics in the area of femoral fractures, morphological signs of a slowdown in reparative osteogenesis develop with the pathological functional remodeling of bone tissue and microischemia in the bone and, of course, in the surrounding soft tissues.


Full Text

Restricted Access

About the authors

Nurlan D. Batpenov

Scientific Research Institute of Traumatology and Orthopedics

Author for correspondence.
Email: niitokz@mail.ru
ORCID iD: 0000-0001-5607-3397

Kazakhstan, Nur-Sultan

Doctor of Medical Science, Professor, Corresponding member of Academy of Medicine Science, Director

Serik K. Rakhimov

Scientific Research Institute of Traumatology and Orthopedics; Non-commercial joint-stock company “Astana medical university”,
Nur-Sultan

Email: rakhimovsk@mail.ru

Kazakhstan, Nur-Sultan

Doctor of Medical Science, Professor, Chief Scientific Researcher; Curator of Polytrauma Department, Professor of the Department of traumatology and orthopedics

Alexei A. Stepanov

Scientific Research Institute of Traumatology and Orthopedics

Email: jsars@mail.ru

Kazakhstan, Nur-Sultan

Head of the Department of traumatology No. 2

Didar A. Orasbaev

Scientific Research Institute of Traumatology and Orthopedics

Email: zh.aitykova@mail.ru

Kazakhstan, Nur-Sultan

resident of the traumatology department No. 2 (polytrauma)

Kenzhegul B. Manekenova

Non-commercial joint-stock company “Astana medical university”,
Nur-Sultan

Email: rakhimovsk@mail.ru

Kazakhstan, Nur-Sultan

Doctor of Medical Science, Professor, Head of the Department of Pathologic Anatomy

Gulzira K. Smailova

Non-commercial joint-stock company “Astana medical university”

Email: rakhimovsk@mail.ru

Kazakhstan, Nur-Sultan

Candidate of Medical Science, Assistant of the Department of Pathologic Anatomy

References

  1. Корыткин А.А., Эль Мудни Ю.М., Ковалдов К.А., Новикова Я.С., Белоусов Б.Ю. Результаты лечения пациентов с перипротезными переломами бедренной кости после эндопротезирования тазобедренного сустава. Травматология и ортопедия России. 2018;24(3):34-44. [Korytkin AA, El Mudni YuM, Kovaldov KA, Novikova YaS, Belousov BYu. Outcome of periprosthtic femoral fractures in hip arthroplasty. Travmatologiya i ortopediya Rossii. 2018;24(3):34-44. (In Russ.)] https://doi.org/10.21823/2311-2905-2018-24-3-34-44.
  2. Матвейчук И.В., Карпов И.Н., Омельяненко Н.П., Денисов-Никольский Ю.И., Дорохин А.И., Миронов С.П. Современные возможности оптимизации репаративной регенерации костной ткани. Вестник травматологии и ортопедии им. Н.Н. Приорова. 2002;(4):85-88. [Matveichuk IV, Karpov IN, Omel’yanenko NP, Denisov-Nikol’skii YuI, Dorokhin AI, Mironov SP. Modern opportunities for optimizing the reparative regeneration of bone tissue. Vestnik travmatologii i ortopedii im. N.N. Priorova. 2002;(4):85-88. (In Russ.)]
  3. Миханов В.А., Полякова В.С., Копылов В.А., Мхитарян Е.Е., Мещеряков К.Н., Бакаева Н.Р., Шурыгина Е.И. Репаративный гистогенез костной ткани в условиях открытого перелома диафиза длинной трубчатой кости у крыс при использовании препарата «Винфар». Современные проблемы науки и образования. 2015;(3):73. [Mikhanov VA, Polyakova VS, Kopylov VA, Mkhitaryan YY, Meshcheryakov KN, Bakaeva NR, Shurygina YI. Reparative histogenesis of bone tissue in an open shaft fractures of long bones in rats with preparations «Vinfar». Sovremennye problemy nauki i obrazovaniya. 2015;(3):73. (In Russ.)]
  4. Неверов В.А., Мирошниченко О.И., Мирошниченко А.П. Особенности реабилитации пациентов после неинфекционных осложнений тотального эндопротезирования тазобедренного сустава. Вестник хирургии им. И.И. Грекова. 2016;175(2):66-72. [Neverov VA, Miroshnichenko OI, Miroshnichenko AP. Features of the rehabilitation of patients after non-infectious complications of total hip arthroplasty. Vestnik khirurgii im. I.I. Grekova. 2016;175(2):66-72. (In Russ.)]
  5. Нуриев Р.И., Сушенцев Н.А., Яковлев В.В. Регенеративная медицина: обзор. В кн.: Сборник материалов Международной биологической универсиады МГУ им. М.В. Ломоносова. М.: МГУ; 2013. [Nuriev RI, Sushentsev NA, Yakovlev VV. Regenerative medicine: a review. In: Proceedings of the International Biological Universiade of Moscow State University n.a. M.V. Lomonosov. Moscow: MSU; 2013. (In Russ.)]
  6. Нуждин В.И., Троценко В.В., Попова Т.П., Каграманов С.В. Ревизионное эндопротезирование тазобедренного сустава. Вестник травматологии и ортопедии им. Н.Н. Приорова. 2001;(2):66-71. [Nuzhdin VI, Trotsenko VV, Popova TP, Kagramanov CV. Revision hip arthroplasty. Vestnik travmatologii i ortopedii im. N.N. Priorova. 2001;(2):66-71. (In Russ.)]
  7. Полевой Е.В., Завгородний Н.В., Каграманов С.В, Чрагян Г.А., Алексанян О.А. Интраоперационные перипротезные переломы бедренной кости при эндопротезировании тазобедренного сустава. Обзор классификации и методов лечения. Вестник травматологии и ортопедии им. Н.Н. Приорова. 2019;(2):67-72. [Polevoy EV, Zagorodniy NV, Kagramanov CV, Chragyan GA, Aleksanyan OA. Interoperative periprosthetic femoral fractures at total hip artroplasty. Review of classifications and treatment technigues. Vestnik travmatologii i ortopedii im. N.N. Priorova. 2019;(2):67-72. (In Russ.)] https://doi.org/10.17116/vto201902167.
  8. Пивень И.М., Бердюгин К.А. Классификация перипротезных переломов бедренной кости (обзор литературы). Современные проблемы науки и образования. 2016;(2):3. [Piven IM, Berdyugin KA. Classification of periprosthetic fracture of the femur (literature review). Sovremennye problemy nauki i obrasovaniya. 2016;(2):3. (In Russ.)]
  9. Хоминец В.В., Метленко П.А., Богданов А.Н., Кудяшев А.Л., Мироевский Ф.В. Ближайшие результаты лечения больных с перипротезными переломами бедренной кости после эндопротезирования тазобедренного сустава. Траматология и ортопедия России. 2015;(4):70-78. [Khominets VV, Metltnko PA, Bogdanov AN, Kudyashev AL, Miroevsky FV. Immediate results of treatment periprothestic femoral fractures after hip replacement. Travmatologiya i ortopediya Rossii. 2015;(4):70-78. (In Russ.)]
  10. Штейнле А.В. Посттравматическая регенерация костной ткани. Часть 1. Сибирский медицинский журнал (г. Томск). 2009;4(1):101-108. [Shteinle AV. Posttraumatic bone tissue regeneration. Part 1. Sibirskii meditsinskii zhurnal (g. Tomsk). 2009;4(1):101-108. (In Russ.)]
  11. Lewallen DG, Berry DJ. Femoral fractures associated with hip arthroplasty. Reconstructive surgery of the joints. 1993;2(5):1273-1288.
  12. Tsiridis E, Narvani AA, Lin Sin Cho G, Timperley J, Gie GA. 144 periprosthetic femoral fractures. Treatment and outcome. J Bone Joint Surg. 1997;86-B:303-d.
  13. Tamaki T, Jonishi K, Miura Y, Oinuma K, Shiratsuchi H. Cementles stapered-wedge stem length affects the risk of periprotesthetic femoral fractures in direct anterior total hip arthroplasty. J Arth. 2018;33(3):805-809. https://doi.org/10.1016./i.arth.2017.09.065.
  14. Villanueva-Lopez F, Psychoyios VN, Esteo-Perez I, Zambiakis E. Periprosthetic supracondylar fracture of the femur. Is it the end of limb function? J Bone Joint Surg. 2003;85-B:234-d.
  15. Wang YC, Hsu CC, Chu YJ, Hsueh TM. An experimental microangiographic study of bone. Chin Med J. 1965;84(6):362-385.

Supplementary files

Supplementary Files Action
1.
Fig. 1. Destructive changes in periprosthetic fractures bone tissue of the femoral component: a — destroyed bone beams with focal accumulations of small bone fragments; b — axillary osteolysis in cartilage ossification fabrics. Staining with hematoxylin and eosin. Magnification × 160

Download (526KB) Indexing metadata
2.
Fig. 2. Reparative changes in periprosthetic fractures bone tissue of the femoral component. The zone of formation of immature bone tissue with a predominance of loosely fibrous interstitial tissue containing many neglected thin-walled vessels. Staining with hematoxylin and eosin. Magnification × 100

Download (334KB) Indexing metadata
3.
Fig. 3. Reparative changes in periprosthetic fractures bone tissue of the femoral component: between the mature bone trabeculae — a section of chondroid metaplasia of bone tissue basic substance of fibrous structure. Staining according to Van Gieson. Magnification × 160

Download (314KB) Indexing metadata
4.
Fig. 4. Reparative changes in periprosthetic fractures bone tissue of the femoral component: proliferation of fibrous tissue around the fragments of the bone beams. Staining with hematoxylin and eosin. Magnification × 160

Download (471KB) Indexing metadata
5.
Fig. 5. Reparative changes in periprosthetic fractures bone tissue of the femoral component: hyperplasia of osteoblasts located along the forming bone trabeculae. Staining with hematoxylin and eosin. Magnification × 200

Download (353KB) Indexing metadata
6.
Fig. 6. Reparative changes in periprosthetic fractures bone tissue of the femoral component: enchondral ossification. Staining with hematoxylin and eosin. Magnification × 200

Download (227KB) Indexing metadata
7.
Fig. 7. Reparative changes in periprosthetic fractures bone tissue of the femoral component. In muscle tissues: pronounced interstitial edema, areas of fibrosis with uneven lymphocytic infiltration mixed with histiocytes and leukocytes. Staining with hematoxylin and eosin. Magnification × 100

Download (337KB) Indexing metadata
8.
Fig. 8. Reparative changes in periprosthetic fractures bone tissue of the femoral component: productive inflammation in adipose tissue with clumps of macrophages

Download (688KB) Indexing metadata
