Volume 25, Nº 3 (2024)
- Ano: 2024
- ##issue.datePublished##: 15.11.2024
- Artigos: 11
- URL: https://journals.eco-vector.com/2712-8970/issue/view/9664
Edição completa
On the occasion of centenary of the birth of academician M. F. Reshetnev
The Birth of Siberian Satellite Construction



Innovative technical solutions developed under the leadership of M. F. Reshetnev in the creation of the first Siberian launcher “Cosmos-3M”
Resumo
Academician Mikhail Fedorovich Reshetnev is one of the outstanding scientists, designers and production organizers who stood at the origins of the development of rocket and space technology in our country and made a significant contribution to domestic and world cosmonautics. 2024 marks the 100th anniversary of his birth and the 60th anniversary of the first launch of the Kosmos-3 launch vehicle (LV), created under his leadership in the Krasnoyarsk Territory.
The article discusses the main stages of design, development work, flight design tests and the launch of mass production of the rocket. It is noted that the creation of the PH was carried out mainly at the production base of the Krasnoyarsk Machine-Building Plant. The most important events related to the organization of the OKB-1 branch, which was then transformed into an independent OKB, are described in chronological order. The role of M.F.'s personality is shown. Reshetnev in solving complex scientific, technical, organizational and production problems of mastering new technology in the Siberian region, remote from the rocket, space and scientific centers of the country.
Information is provided on innovative technical solutions developed under the guidance of M. F. Reshetnev during the creation of the Kosmos-3 launch vehicle and its subsequent modification. It is noted that M. F. Reshetnev in his scientific and technical activities constantly received the support of S. P. Korolev and M. K. Yangel, successfully cooperated with the largest design organizations headed by V. P. Glushko, A. M. Isaev, V. G. Sergeev and other well-known leaders and specialists of the rocket and space industry.



Section 2. Aviation and Space Technology
Development of a methodology and design of a device for determining the Mach number of a supersonic flow
Resumo
The paper presents the developed methodology and designed a device for determining the Mach number during supersonic gas outflow. An analysis of various methods for determining the Mach number was carried out, including measuring the pressure at the flow boundary, the use of shock waves, and the use of optical methods. A comparison was made of the accuracy of the readings when using the considered methods. Based on the results obtained, a technique for high-precision determination of the Mach number has been developed, including a combination of several independent measurement methods. A device has been designed that implements this measurement technique, and the results of experimental tests in a wind tunnel have been reviewed, including instrument readings, graphs and tables confirming the accuracy and reliability of the data obtained. Their accuracy and reliability are analyzed. Using the analysis, it is possible to ensure the selection of the most rational method for determining the Mach number at the initial stage of designing aircraft, such as airplanes, missiles, fighters, and UAVs. Accurate knowledge of the Mach number allows engineers to optimize the aerodynamic characteristics of the aircraft, ensure flight safety, improve engine efficiency and overall air transport performance. In addition, the Mach number is the most important criterion of similarity when modeling in aerodynamic research, which makes the developed methodology and device relevant not only for the design of aircraft, but also for a wide range of scientific and engineering research in the field of aeronautical technology. It is emphasized that the presence of a reliable method for determining the Mach number can significantly reduce the time and resources spent on testing and improving aircraft, and also contributes to the development of innovative technologies in the field of aviation and astronautics.



Three-component aerodynamic load cells
Resumo
The article examines the effect of flow on models studied in wind tunnels. To determine the force effect of the flow on the model under study, a more accurate and reliable method of directly measuring forces and moments using aerodynamic strain gauge balances is proposed. When solving a plane problem for a symmetrical model at zero slip angle, a design of three-component scales is proposed that measures the lift force, the drag force and the pitching moment. To eliminate the interaction between the supporting devices and the model, which causes disturbances in the flow near the model, the scales are located outside the model and the working part of the wind tunnel. The components of the aerodynamic force and moment acting on the model are measured using resistance strain gauges, which convert the deformation of the elastic element into a change in electrical resistance, which is measured by an instrument connected to an appropriate measuring circuit. The choice of strain gauges as weight elements is due to their very small size and weight, the ability to measure very small relative deformations of elastic elements, low inertia, which makes it possible to measure not only static but also dynamic loads, and the possibility of remote measurements. To compensate for the influence of various sources of errors, increase sensitivity and ensure greater measurement accuracy, the strain gauges are connected via a bridge circuit and included in all four arms of the bridge. Deformation of the horizontal measuring beam causes a change in resistance not only in the strain gauges that measure the pitching moment, but also in the strain gauges designed to measure the lift force. Since the design of the scales does not allow for electrical separation of these components, the influence of the pitching moment on the magnitude of the lift force is determined during the calibration process and is assessed using a special influence graph constructed from the results of calibration data. In strain gauge measurements, the output values of forces and moments acting on the model under test are obtained in the form of corresponding readings from a device that measures electrical signals proportional to the applied forces. To convert instrument data into values of forces and moments, a joint calibration of scales and instruments is carried out in order to obtain calibration coefficients. Additional components of aerodynamic forces and moments created by the holder are determined by purging it in the presence of the model. Calculated dependencies for determining the components of the aerodynamic impact are given. The values of the coefficients of aerodynamic forces and moments are given in the flow coordinate system. The pledge has been given.



Implementation of additive 3D printing technology in the development of an experimental oxygen-hydrogen low thrust rocket engine
Resumo
The creation of spacecraft propulsion systems with high energy efficiency and minimal weight and size parameters is an urgent scientific and technical task of the domestic rocket engine industry. At the same time, requirements are put forward to optimize the cost and time of design, development and manufacturing of engines, as well as environmental safety at all stages of the product life cycle. In this regard, it is proposed to use advanced laser 3D printing technologies (additive technologies) from metal powder using CAD models of engine parts in the production of space low thrust rocket engines (LTRE).
Laser melting technology on modern 3D printers makes it possible to produce complex monolithic engine structures without the use of labor-intensive and resource-intensive operations of machining, welding, and soldering, as well as a significant reduction in the volume of plumbing, assembly, control and measuring work, and a decrease in the influence of some non-production factors.
The article discusses issues of practical application of promising technologies in the creation of LTRE. The results of fire tests are presented, which will be used to refine the previously developed calculation models of oxygen-hydrogen LTRE when creating advanced rocket engines for spacecraft.
The object of the study was an experimental sample of LTRE with a nominal thrust of 150 N using gaseous fuel components oxygen and hydrogen, developed and manufactured using additive technology. The experimental LTRE is considered as a prototype of the engine for orientation, stabilization and launching of the oxygen-hydrogen upper stage. The purpose of the work is to study the effectiveness of previously unexplored design solutions for organizing mixture formation and cooling of an oxygen-hydrogen LTRE, to determine their influence on the perfection of the working process and the thermal state of the engine chamber. Fire tests were carried out in single switching mode with a duration sufficient for the LTRE chamber to reach a stationary thermal regime, with the determination of the energy characteristics and thermal state of the structure.



Comparative analysis of methods for regulating the frequency characteristics of simulators of electrical characteristics of spacecraft power supply systems
Resumo
One of the main systems of a spacecraft (SC) is the power supply system (PSS). The basis of PDS are secondary power sources (SPS), which use various methods of controlling and converting electricity, which leads to significant differences in their dynamic properties. From the side of on-board consumers, the dynamics of the power transmission system is determined by the total internal resistance (impedance) of the VIP.
When conducting ground electrical tests of spacecraft ETS, due to the complexity of using power supply systems, test complexes are used, the basis of which is simulators of electrical characteristics of electric power transmission systems (EPTS).
Modern ISPS use a modular configuration principle, which makes it possible to produce EPTS of different powers, but energy modules have fixed or adjustable impedance frequency characteristics over a narrow frequency range, which leads to a limitation of the types of simulated PSPS. Equipping the EPTS with the property of regulating frequency characteristics in a wide frequency range expands the functionality of the EPTS, as it allows you to simulate the dynamic properties of the PSEP containing different types of VIPs.
The purpose of the work is to study and comparative analysis of three methods for regulating the impedance frequency characteristics (IFC) of the EPTS module.
Methods for regulating the frequency response of an EPTS are considered on the basis of its generalized functional diagram containing mathematical models: amplifier-adder (AS), serial correction device (CU), power amplifier (PA), voltage divider (DN) and load (L). The article analyzes options for regulating the impedance frequency characteristics of EPTS, and considers three methods for regulating the IFC: two with a passive correction device and one with an active CU.
The paper presents a simulation model in the MicroCap package of the electrical circuit of the EPTS module, and computational experiments have been carried out on each method of regulating the IFC of the EPTS.
Based on the results of the study, a method for correcting and regulating the IFC of the EPTS is recommended, which makes it possible to separately regulate the low-frequency and mid-frequency regions of the IFC, which makes it possible to significantly simplify the configuration and provision of the IFC of the EPTS in accordance with the specified requirements.



Increasing the capabilities of a test ballistic missile to separate test objects
Resumo
The subject of this study is the trajectory characteristics of the long-range test ballistic missile (TBM).
The purpose of the study is to increase the capabilities of TBM in separating test object (TO). At the same time, as a generalized quantitative measure of this increasing the post-boost vehicle (PBV) fuel reserve consumed for separation of TO is taken.
The design-ballistic task of rationalizing the distribution of the available fuel of the TBM DS between the following main characteristic section of its flight has been set and numerically and analytically solved: final sustainer stage underperformance compensation; turns with subsequent angular stabilization, retreats and lead away; TO disconnection (separation section).
As a result, it is shown that without reducing the quality of TBM launch tasks, it is permissible to redistribute the consumed fuel of the PBV between these section relative to the distribution for a standard ballistic missile (SBM), leading to a significant increase in its reserve consumed in the section of disconnection of the TO (when flying along the ballistic vertical).
At the same time, the purpose of the study is achieved – the capabilities of the TBM in the separation of the TO are increased, which, while direct planning of launches is evaluating, can be expressed in an increase in the number and/or total mass of the TO and/or an increase in speed or time intervals in the order of sequential disconnections of the TO.
The given numerical examples (using a converted three-stage SBM as a TBM) also show a significant dependence of the amount of fuel increment of the PBV consumed at the TO disconnections of the trajectory conditions of test launches (the corresponding initial data (ID) for calculations are borrowed from the author’s previously published work): length of the route; kinematic parameters of launch at the moment of independent PBS flight beginning determined by the launch task.
During the study, methods of flight theory and design ballistics of LR missiles were used.
As a conclusion, it can be noted that the considered task and methods for its solution can be useful (of course, taking into account the necessary specialized improvements) in works of the executive ballistics level when planning and evaluating the result of TBM launches.



Development of an experimental unit and methodology for ground-based experimental testing of two-phase thermoregulation systems for spacecrafts
Resumo
This article presents a detailed description of an experimental setup for testing two-phase thermal control systems of spacecraft. The setup is a climatic chamber for simulating real operating conditions of elements in the subzero temperature range and includes three circuits: a coolant pumping circuit corresponding in parameters to the thermal control system under study, a cooling system circuit, and a thermal load simulator circuit. Electric heating elements are used as a thermal load simulator. Transparent inserts provide the ability to visually monitor the structure of a two-phase flow during boiling and estimate the volume content of the vapor phase.
A testing methodology was developed for the installation under consideration, including a testing algorithm and a description of the software and hardware testing tools. The software and hardware testing tools include electronic measuring tools for the main parameters of the operating modes of the two-phase thermal control system and an automated testing process control system.
The developed automated testing process control system provides the ability to monitor a wide range of thermal and physical parameters of the coolant at various points in the circuit. The control system is based on the use of programmable logic controllers. To automate the operation of the installation, the OWEN PLC200 controller is used in the stand – a monoblock controller with discrete and analog inputs/outputs, designed to control and manage the operating modes of small systems. The software part of the algorithm is based on the CODESYS environment.
The results obtained in the work can be used in planning and implementing programs for ground-based experimental testing of two-phase thermal control systems, in developing test stands for conducting research on spacecraft systems.



Section 3. Technological Processes and Materials
Development of the two-fuel combustion chamber and calculation of processes for the theory of turbulent burning
Resumo
In this material development stages of the two-fuel combustion chamber for the HK-16-18CT engine are presented. Calculation of processes on the basis of the theory of turbulent burning is made.
One of competitive advantages of stationary gas-turbine installation is the possibility of work on two types of fuel: on diesel and on gaseous. Therefore creation of the two-fuel combustion chamber is relevant. The designing process of the two-fuel combustion chamber consists of several stages. At the first stage the nozzle is developed. It is equipped with two internal fuel channels. Then the front device is designed. in it nozzles are placed in two ranks. This device is equipped with two separate fuel collectors. It contains cavities for a fuel supply to two channels of nozzles. Such constructive decision allows to carry out switching of one type of fuel to another without stopping operation of the engine. As a prototype for distribution of air on length of a spherical pipe the combustion chamber of the NK-8-2U engine is taken.
Calculation of processes in the combustion chamber was carried out on the basis of the theory of turbulent burning. During calculation such parameters as the normal speed of burning, the pulsation speed, coefficient of turbulent exchange, scale of turbulence and intensity of turbulence are determined.
The equation of thermal balance for determination of temperature in the considered area at combustion of natural gas and diesel fuel is created. It is considered what in one case is spent warmly going for evaporation of liquid fuel, in other case it is not necessary.
For calculation of formation of nitrogen oxides Ya. B. Zeldovich's theory of thermal oxidation of nitrogen is used by oxygen. Emissions of carbon monoxide are determined by an empirical formula
From gasdynamic calculation of the HK-16-18CT engine parameters on an entrance to the combustion chamber on various operating modes at combustion of natural gas are known.
Calculation for definition of a necessary consumption of diesel fuel for power setting at preservation of temperature at the exit is executed from the combustion chamber.
By results of calculation the schedule of emission of harmful substances from power setting on gas and diesel fuels is constructed. The comparative schedule of dependence of completeness of combustion of fuel on power setting is constructed.
Settlement emissions of harmful substances of the developed combustion chamber in the range of operation of the engine on power from 0,7Ne to 1 Ne for liquid fuel: NOx15%O2 does not exceed 250 mg/m3, СO15%О2 does not exceed 300 mg/m3; for gaseous NOx15%O2 fuel does not exceed 120 mg/m3, СO15%О2 does not exceed 150 mg/m3.



Specificity of defect formation in detectors based on cadmium telluride under pulse thermal influence
Resumo
Active development of high technologies in the aerospace industry requires consideration of the operation of devices and equipment under extreme conditions; it is important to study the degradation of materials during rapid heating and cooling. In this paper, based on the theoretical and experimental work performed, we consider the degradation of cadmium telluride detectors caused by the development and evolution of a network of point defects caused by pulsed exposure with a heat dose of about 1000 ºС for no more than 10 seconds, simulating an extreme situation of a short circuit near the detector or direct heating by light pulses. The study showed that the crystalline material quickly degrades under such extreme conditions due to the rapid evolution of the defect network. The phenomenological model of the formation and distribution of defects during short-term exposure of the detector to thermal radiation has been improved. Electron microscopic studies of samples exposed to pulsed infrared radiation showed the development of a dense defect network, vacancy and interstitial defects, clusters and other damage in all samples.



The effect of laser texturing of the surface of a titanium alloy on the adhesive strength of adhesive joints
Resumo
The paper examines issues related to the influence of laser texturing of the surface of a titanium alloy on the characteristics of the titanium-carbon fiber adhesive joint. Using an ytterbium pulsed fiber laser, textures with a linear structure (0°–0° and 90°–90°) and a mesh structure (0°–90°, ±30°, ±45°, ±60°) were created on the surface of a titanium alloy. The surface roughness values in two perpendicular directions were determined, and microsections were made, which can be used to characterize the surface morphology of the titanium alloy. To determine the adhesive strength of the joint, samples with the same surface texture were glued together. The samples were glued together according to OST 1-90281–86. Bonding was carried out within 24 hours after laser surface treatment. Before gluing, the treated surface was cleaned with isopropyl alcohol. Adhesive joint area S = 300 mm2. Three-component adhesive VK-9 based on epoxy and polyamide resin was used as an adhesive. Laser surface treatment of titanium alloys increases the strength of the adhesive joint by more than 70 % relative to the untreated surface. This may indicate that the main mechanisms for increasing the strength of an adhesive joint are an increase in the contact area between the surface and the adhesive, and chemical modification that activates the surface. The processing texture has a lesser effect on the adhesive strength, provided that the specific surface energy of the laser processing is the same. When laser processing, you should pay great attention to the choice of surface texture, because certain textures can give an increase in strength by 20–30 %. If the type of load in the truss load elements is known, then it is better to use linear textures directed perpendicular to the direction of the load (for shear – texture 0°–0°; for torsion – texture 90°–90°). For mixed loads, it is better to use mesh structures ±30°, ±45°, ±60°, which resist loads in two directions.
